Audi A1 wheel fitment — 8X
Overview
The Audi A1 is a luxury supermini car launched by Audi at the 2010 Geneva Motor Show. Sales of the initial three-door model started in Germany in August 2010, with the United Kingdom following in November 2010. The five-door Sportback variant was introduced in November 2011 and began sales in export markets early in 2012. Built on the Volkswagen Group PQ25 platform, it uses a MacPherson strut front suspension and torsion beam rear suspension. The A1 is aimed at young, affluent urban buyers and offers various trim levels including SE, Sport, and S line.
History & notable variants
The concept for the Audi A1 was previewed as the metroproject quattro in 2007 and later renamed to A1 Project Quattro in 2008. The production version of the A1 three-door went on sale in late 2010, followed by the five-door Sportback variant in early 2012. Notable special editions include the Motto Vehicles series from Wörthersee Tour 2010 and the Contrast Edition introduced mid-2011.
Audi A1 wheel fitment
Everything below is what the fit-check uses for Audi A1 wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Audi A1 8X.
| Bolt pattern (PCD) | 5x100 |
| Centre bore | 57.1 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 125 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6J–8J | ET24–ET45 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.0 TFSI ultra | VW EA211, 999 cc, CHZE | petrol | 60 kW (82 PS) | FWD, 2016 to 2018 |
| 1.0 TFSI ultra | VW EA211, 999 cc, CHZB | petrol | 70 kW (95 PS) | FWD, 2015 to 2018 |
| 1.2 TFSI | VW EA111, 1,197 cc, CBZA | petrol | 63 kW (86 PS) | FWD, 2010 to 2014 |
| 1.4 TFSI | VW EA111, 1,390 cc, CAXA, CNVA | petrol | 90 kW (122 PS) | FWD, 2010 to 2014 |
| 1.4 TFSI | VW EA211, 1,395 cc, CZCA | petrol | 92 kW (125 PS) | FWD, 2014 to 2018 |
| 1.4 TFSI COD | VW EA211, 1,395 cc, CPTA | petrol | 103 kW (140 PS) | FWD, 2013 to 2014 |
| 1.4 TFSI COD | VW EA211, 1,395 cc, CZEA | petrol | 110 kW (150 PS) | FWD, 2014 to 2018 |
| 1.4 TFSI | VW EA111, 1,390 cc, CAVG, CTHG | petrol | 136 kW (185 PS) | FWD, 2010 to 2014 |
| 1.8 TFSI | VW EA888, 1,798 cc, DAJB | petrol | 141 kW (192 PS) | FWD, 2014 to 2018 |
| 2.0 TFSI (S1) | VW EA888, 1,984 cc, CWZA | petrol | 170 kW (231 PS) | quattro, 2014 to 2018 |
| 2.0 TFSI / (A1 quattro) | VW EA113, 1,984 cc, CDLH | petrol | 188 kW (256 PS) | quattro, 2012 |
| 1.4 TDI ultra | VW EA288, 1,422 cc, CUSB | diesel | 66 kW (90 PS) | FWD, 2014 to 2018 |
| 1.6 TDI | VW EA189, 1,598 cc, CAYB | diesel | 66 kW (90 PS) | FWD, 2011 to 2014 |
| 1.6 TDI | VW EA189, 1,598 cc, CAYC | diesel | 77 kW (105 PS) | FWD, 2010 to 2014 |
| 1.6 TDI | VW EA288, 1,598 cc, CXMA | diesel | 85 kW (116 PS) | FWD, 2014 to 2018 |
| 2.0 TDI | VW EA189, 1,968 cc, CFHD | diesel | 105 kW (143 PS) | FWD, 2011 to 2014 |
Source: Audi A1 8X, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 1.0 TFSI ultra | 60 kW (82 PS) | 12.4 to 12.6 s | |
| 1.0 TFSI ultra | 70 kW (95 PS) | 10.9 to 11.1 s | |
| 1.2 TFSI | 63 kW (86 PS) | 11.7 to 11.9 s | |
| 1.4 TFSI | 90 kW (122 PS) | 8.9 to 9 s | |
| 1.4 TFSI | 92 kW (125 PS) | 8.8 to 8.9 s | |
| 1.4 TFSI COD | 103 kW (140 PS) | 7.9 to 8 s | |
| 1.4 TFSI COD | 110 kW (150 PS) | 7.8 to 7.9 s | |
| 1.4 TFSI | 136 kW (185 PS) | 6.9 to 7 s | |
| 1.8 TFSI | 141 kW (192 PS) | 6.8 to 6.9 s | |
| 2.0 TFSI (S1) | 170 kW (231 PS) | 5.8 to 5.9 s | |
| 2.0 TFSI / (A1 quattro) | 188 kW (256 PS) | 5.7 s | |
| 1.4 TDI ultra | 66 kW (90 PS) | 11.4 to 11.6 s | |
| 1.6 TDI | 66 kW (90 PS) | 11.4 to 11.6 s | |
| 1.6 TDI | 77 kW (105 PS) | 10.5 to 10.7 s | |
| 1.6 TDI | 85 kW (116 PS) | 9.4 to 9.5 s | |
| 2.0 TDI | 105 kW (143 PS) | 8.2 to 8.3 s |
Source: Audi A1 8X, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 268,300 Audi A1 on UK roads, placing it in the top 1% of car models by volume across our fitment database.
That makes Audi A1 wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 3,954 to 3,987 mm |
| Width | 1,740 to 1,746 mm |
| Height | 1,416 to 1,422 mm |
| Wheelbase | 2,469 mm |
| Kerb weight | 1,110 to 1,290 kg |
Source: Audi A1 8X, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | 3/5-door hatchback |
| Produced | 2010–2015 |
| Units produced | 1,389,658 |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Luxury features in a compact package; strong brand reputation; good build quality
- Cons: Limited rear seat and cargo space; higher price point compared to non-luxury superminis
- Common issues: None reported
