Audi A4 wheel fitment — B8 Facelift
Overview
The Audi A4 B8 Facelift is part of the fifth generation (B8) of the luxury compact executive car produced by Audi AG, a subsidiary of Volkswagen Group. It was built on the Volkswagen Group MLB platform and succeeded the fourth-generation Audi 80/90 series. The B8 generation introduced significant changes over its predecessor, including an updated design language, improved interior quality, and enhanced technology features such as MMI (Multi Media Interface) navigation system. Production took place in Ingolstadt, Germany; Changchun, China; and Aurangabad, India.
Audi A4 wheel fitment
Start with the hub. The Audi A4 B8 Facelift spec table gives the bolt pattern and bore; the second table is the aftermarket window for Audi A4 wheel fitment.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–8.5J | ET18–ET45 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 242,314 Audi A4 on UK roads, placing it in the top 1% of car models by volume across our fitment database.
A parc that size is why Audi A4 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.8 TFSI | VW EA888, 1,798 cc | petrol | 88 kW (120 PS) | FWD, 2008 to 2015 |
| 1.8 TFSI | VW EA888, 1,798 cc | petrol | 118 kW (160 PS) | FWD or AWD, 2007 to 2011 |
| 1.8 TFSI | VW EA888, 1,798 cc | petrol | 125 kW (170 PS) | FWD or AWD, 2011 to 2015 |
| 2.0 TFSI flexible | VW EA888, 1,984 cc | petrol | 132 kW (180 PS) | FWD or AWD, 2009 to 2015 |
| 2.0 TFSI | VW EA888, 1,984 cc | petrol | 132 kW (180 PS) | FWD or AWD, 2008 to 2011 |
| 2.0 TFSI | VW EA888, 1,984 cc | petrol | 155 kW (211 PS) | FWD or AWD, 2008 to 2013 |
| 2.0 TFSI | VW EA888, 1,984 cc | petrol | 165 kW (225 PS) | FWD or AWD, 2013 to 2015 |
| 3.0 TFSI | VW EA837, 2,995 cc | petrol | 200 kW (272 PS) | quattro, 2012 to 2015 |
| 3.0 TFSI (S4) | VW EA837, 2,995 cc | petrol | 245 kW (333 PS) | quattro, 2008 to 2015 |
| 3.2 FSI | VW EA837, 3,197 cc | petrol | 195 kW (265 PS) | FWD or AWD, 2007 to 2011 |
| 4.2 FSI (RS4) | VW EA824, 4,163 cc | petrol | 331 kW (450 PS) | AWD, 2012 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 88 kW (120 PS) | FWD, 2008 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 100 kW (136 PS) | FWD, 2009 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 105 kW (143 PS) | FWD or AWD, 2007 to 2013 |
| 2.0 TDI | VW EA288, 1,968 cc | diesel | 110 kW (150 PS) | FWD or AWD, 2013 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 120 kW (163 PS) | FWD, 2011 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 125 kW (170 PS) | FWD or AWD, 2008 to 2011 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 130 kW (177 PS) | FWD or AWD, 2011 to 2015 |
| 2.0 TDI | VW EA288, 1,968 cc | diesel | 140 kW (190 PS) | FWD or AWD, 2014 to 2015 |
| 2.7 TDI | VW EA896, 2,698 cc | diesel | 140 kW (190 PS) | FWD, 2007 to 2011 |
| 3.0 TDI | VW EA896G2, 2,967 cc | diesel | 150 kW (204 PS) | FWD, 2011 to 2015 |
| 3.0 TDI | VW EA896, 2,967 cc | diesel | 176 kW (240 PS) | quattro, 2007 to 2011 |
| 3.0 TDI | VW EA896G2, 2,967 cc | diesel | 180 kW (245 PS) | quattro, 2011 to 2015 |
Source: Audi A4 B8, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 1.8 TFSI | 88 kW (120 PS) | 10.5 to 10.8 s | |
| 1.8 TFSI | 118 kW (160 PS) | 8.6 to 8.9 s | |
| 1.8 TFSI | 125 kW (170 PS) | 7.9 to 8.3 s | |
| 2.0 TFSI flexible | 132 kW (180 PS) | 7.7 to 8.1 s | |
| 2.0 TFSI | 132 kW (180 PS) | 7.7 to 8.6 s | |
| 2.0 TFSI | 155 kW (211 PS) | 6.5 to 7.4 s | |
| 2.0 TFSI | 165 kW (225 PS) | 6.4 to 6.9 s | |
| 3.0 TFSI | 200 kW (272 PS) | 5.9 to 6.1 s | |
| 3.0 TFSI (S4) | 245 kW (333 PS) | 5 to 5.4 s | |
| 3.2 FSI | 195 kW (265 PS) | 6.2 to 6.6 s | |
| 4.2 FSI (RS4) | 331 kW (450 PS) | 4.7 s | |
| 2.0 TDI | 88 kW (120 PS) | 10.5 to 11.2 s | |
| 2.0 TDI | 100 kW (136 PS) | 9.3 to 9.8 s | |
| 2.0 TDI | 105 kW (143 PS) | 9.1 to 10.3 s | |
| 2.0 TDI | 110 kW (150 PS) | 9.1 to 9.7 s | |
| 2.0 TDI | 120 kW (163 PS) | 8.3 to 8.7 s | |
| 2.0 TDI | 125 kW (170 PS) | 8.3 to 8.9 s | |
| 2.0 TDI | 130 kW (177 PS) | 7.8 to 8.4 s | |
| 2.0 TDI | 140 kW (190 PS) | 7.3 to 8.3 s | |
| 2.7 TDI | 140 kW (190 PS) | 7.7 to 8.2 s | |
| 3.0 TDI | 150 kW (204 PS) | 7.1 to 7.9 s | |
| 3.0 TDI | 176 kW (240 PS) | 6.1 to 6.6 s | |
| 3.0 TDI | 180 kW (245 PS) | 5.9 to 6.3 s |
Source: Audi A4 B8, de.wikipedia.org.
Dimensions
| Length | 4,699 to 4,761 mm |
| Width | 1,826 to 1,850 mm |
| Height | 1,406 to 1,495 mm |
| Wheelbase | 2,805 to 2,813 mm |
| Kerb weight | 1,395 to 1,840 kg |
Source: Audi A4 B8, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | 4-door saloon/sedan, 5-door Avant (estate/wagon) |
| Produced | 2011–2016 |
Trim levels
Factory colours
History & notable variants
The Audi A4 B8 Facelift underwent notable changes to enhance its appeal and competitiveness in the market. These included aesthetic updates like new front and rear styling elements, improved lighting technology, and revised interior trims. Performance variants such as the S4 and RS 4 were also introduced or updated during this period.
Reliability & owner notes
- Pros: Updated design; improved interior quality; enhanced technology features
- Cons: No specific weaknesses mentioned in the reference
