Audi A4 wheel fitment — B8
Audi A4 wheel fitment
Audi A4 wheel fitment for the Audi A4 B8 (2007–2012): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–8.5J | ET18–ET45 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 242,314 Audi A4 on UK roads, placing it in the top 1% of car models by volume across our fitment database.
That makes Audi A4 wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Overview
The Audi A4 is a line of luxury compact executive cars produced from 1994 to 2025 by the German car manufacturer Audi, a subsidiary of the Volkswagen Group. The B8 and B9 versions of the A4 are built on the Volkswagen Group MLB platform shared with several models and brands across the Volkswagen Group. It has been manufactured in Ingolstadt since its beginning, in Changchun China by FAW-VW since 2003 and in Aurangabad India by Audi India since 2007.
Dimensions
| Length | 4,699 to 4,761 mm |
| Width | 1,826 to 1,850 mm |
| Height | 1,406 to 1,495 mm |
| Wheelbase | 2,805 to 2,813 mm |
| Kerb weight | 1,485 to 1,840 kg |
Source: Audi A4 B8, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | 4-door saloon/sedan, 5-door Avant (estate/wagon) |
| Produced | 2007–2012 |
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.8 TFSI | VW EA888, 1,798 cc | petrol | 88 kW (120 PS) | FWD, 2008 to 2015 |
| 1.8 TFSI | VW EA888, 1,798 cc | petrol | 118 kW (160 PS) | FWD or AWD, 2007 to 2011 |
| 1.8 TFSI | VW EA888, 1,798 cc | petrol | 125 kW (170 PS) | FWD or AWD, 2011 to 2015 |
| 2.0 TFSI flexible | VW EA888, 1,984 cc | petrol | 132 kW (180 PS) | FWD or AWD, 2009 to 2015 |
| 2.0 TFSI | VW EA888, 1,984 cc | petrol | 132 kW (180 PS) | FWD or AWD, 2008 to 2011 |
| 2.0 TFSI | VW EA888, 1,984 cc | petrol | 155 kW (211 PS) | FWD or AWD, 2008 to 2013 |
| 2.0 TFSI | VW EA888, 1,984 cc | petrol | 165 kW (225 PS) | FWD or AWD, 2013 to 2015 |
| 3.0 TFSI | VW EA837, 2,995 cc | petrol | 200 kW (272 PS) | quattro, 2012 to 2015 |
| 3.0 TFSI (S4) | VW EA837, 2,995 cc | petrol | 245 kW (333 PS) | quattro, 2008 to 2015 |
| 3.2 FSI | VW EA837, 3,197 cc | petrol | 195 kW (265 PS) | FWD or AWD, 2007 to 2011 |
| 4.2 FSI (RS4) | VW EA824, 4,163 cc | petrol | 331 kW (450 PS) | AWD, 2012 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 88 kW (120 PS) | FWD, 2008 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 100 kW (136 PS) | FWD, 2009 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 105 kW (143 PS) | FWD or AWD, 2007 to 2013 |
| 2.0 TDI | VW EA288, 1,968 cc | diesel | 110 kW (150 PS) | FWD or AWD, 2013 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 120 kW (163 PS) | FWD, 2011 to 2015 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 125 kW (170 PS) | FWD or AWD, 2008 to 2011 |
| 2.0 TDI | VW EA189, 1,968 cc | diesel | 130 kW (177 PS) | FWD or AWD, 2011 to 2015 |
| 2.0 TDI | VW EA288, 1,968 cc | diesel | 140 kW (190 PS) | FWD or AWD, 2014 to 2015 |
| 2.7 TDI | VW EA896, 2,698 cc | diesel | 140 kW (190 PS) | FWD, 2007 to 2011 |
| 3.0 TDI | VW EA896G2, 2,967 cc | diesel | 150 kW (204 PS) | FWD, 2011 to 2015 |
| 3.0 TDI | VW EA896, 2,967 cc | diesel | 176 kW (240 PS) | quattro, 2007 to 2011 |
| 3.0 TDI | VW EA896G2, 2,967 cc | diesel | 180 kW (245 PS) | quattro, 2011 to 2015 |
Source: Audi A4 B8, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 1.8 TFSI | 88 kW (120 PS) | 10.5 to 10.8 s | |
| 1.8 TFSI | 118 kW (160 PS) | 8.6 to 8.9 s | |
| 1.8 TFSI | 125 kW (170 PS) | 7.9 to 8.3 s | |
| 2.0 TFSI flexible | 132 kW (180 PS) | 7.7 to 8.1 s | |
| 2.0 TFSI | 132 kW (180 PS) | 7.7 to 8.6 s | |
| 2.0 TFSI | 155 kW (211 PS) | 6.5 to 7.4 s | |
| 2.0 TFSI | 165 kW (225 PS) | 6.4 to 6.9 s | |
| 3.0 TFSI | 200 kW (272 PS) | 5.9 to 6.1 s | |
| 3.0 TFSI (S4) | 245 kW (333 PS) | 5 to 5.4 s | |
| 3.2 FSI | 195 kW (265 PS) | 6.2 to 6.6 s | |
| 4.2 FSI (RS4) | 331 kW (450 PS) | 4.7 s | |
| 2.0 TDI | 88 kW (120 PS) | 10.5 to 11.2 s | |
| 2.0 TDI | 100 kW (136 PS) | 9.3 to 9.8 s | |
| 2.0 TDI | 105 kW (143 PS) | 9.1 to 10.3 s | |
| 2.0 TDI | 110 kW (150 PS) | 9.1 to 9.7 s | |
| 2.0 TDI | 120 kW (163 PS) | 8.3 to 8.7 s | |
| 2.0 TDI | 125 kW (170 PS) | 8.3 to 8.9 s | |
| 2.0 TDI | 130 kW (177 PS) | 7.8 to 8.4 s | |
| 2.0 TDI | 140 kW (190 PS) | 7.3 to 8.3 s | |
| 2.7 TDI | 140 kW (190 PS) | 7.7 to 8.2 s | |
| 3.0 TDI | 150 kW (204 PS) | 7.1 to 7.9 s | |
| 3.0 TDI | 176 kW (240 PS) | 6.1 to 6.6 s | |
| 3.0 TDI | 180 kW (245 PS) | 5.9 to 6.3 s |
Source: Audi A4 B8, de.wikipedia.org.
Trim levels
Factory colours
History & notable variants
The B8 generation of the A4 was introduced as a significant update to the previous model. It featured an updated design language and improved technology, including enhanced safety features and more efficient engines. The B9 followed with further refinements and modernized aesthetics. Notable special/performance variants include the S4 and RS 4.
Reliability & owner notes
- Pros: null
- Cons: null
- Common issues: null
