Audi RS4 B5 side profile — Audi RS4 wheel fitment

Audi RS4 wheel fitment — B5

By Torque, AIWheelTech vehicle & fitment specialist · 1999–2001
The Audi RS4 B5 (1999–2001) uses a 5x112 bolt pattern, 57.1 mm centre bore, M14x1.5 bolts torqued to ~120 Nm. It accepts ~7.5J–9J wheels at ET10–ET29. That is the short version of Audi RS4 wheel fitment; the full picture is below.

Overview

The Audi RS 4 B5 is a high-performance variant of the Audi A4 range, produced by Audi Sport GmbH for AUDI AG from 1999 to 2001. It sits above the S4 as the fastest and most sports-focused car based on the Volkswagen Group B platform. The RS 4 was available only as an Avant (station wagon) model during this generation, built exclusively in Germany at Audi's Neckarsulm plant. This version succeeded the Porsche/Quattro GmbH-developed Audi RS2 Avant.

History & notable variants

The original B5 RS 4 was introduced late in 1999 for production and sale from 2000 onwards. It featured significant aerodynamic modifications, including unique front and rear bumpers and side sills, achieving a drag coefficient of C<sub>d</sub>&nbsp;0.34. The engine was a 2.7-liter V6 biturbo developed by Cosworth Technology in the UK, producing 280 kW (375 bhp) at 7,000 rpm and 440 N⋅m (325 lb-ft) of torque at 6,000 rpm.

Audi RS4 wheel fitment

Everything below is what the fit-check uses for Audi RS4 wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Audi RS4 B5.

Bolt pattern (PCD)5x112
Centre bore57.1 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque120 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front7.5J–9JET10–ET29

Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.

Browse wheels that fit a Audi RS4 →Get them fitted (UK)

Engines & drivetrain

VariantEngineFuelPowerDrive, years
1.61,595 cc, Motorkenndatenpetrol74 kW (101 PS)FWD, 1994 to 1997
1.61,595 cc, Motorkenndatenpetrol74 kW (101 PS)FWD, 1997 to 2000
1.61,595 cc, Motorkenndatenpetrol75 kW (102 PS)FWD, 2000 to 2001
1.81,781 cc, Motorkenndatenpetrol92 kW (125 PS)FWD or quattro, 1994 to 2001
1.8 T1,781 cc, Motorkenndatenpetrol110 kW (150 PS)FWD or quattro, 1995 to 2001
1.8 T1,781 cc, Motorkenndatenpetrol132 kW (180 PS)FWD or quattro, 1997 to 2001
2.42,393 cc, Motorkenndatenpetrol121 kW (165 PS)FWD or quattro, 1997 to 2001
2.62,598 cc, Motorkenndatenpetrol110 kW (150 PS)FWD or quattro, 1994 to 1997
2.82,771 cc, Motorkenndatenpetrol128 kW (174 PS)FWD or quattro, 1994 to 1997
2.82,771 cc, Motorkenndatenpetrol142 kW (193 PS)FWD or quattro, 1996 to 2001
S42,671 cc, Motorkenndatenpetrol195 kW (265 PS)quattro, 1997 to 2001
RS42,671 cc, Motorkenndatenpetrol280 kW (381 PS)quattro, 2000 to 2001
RS4602,671 cc, Motorkenndatenpetrol338 kW (460 PS)quattro, 2000 to 2001
1.9 DI1,896 cc, Motorkenndatendiesel55 kW (75 PS)FWD
1.9 TDI1,896 cc, Motorkenndatendiesel66 kW (90 PS)FWD
1.9 TDI1,896 cc, Motorkenndatendiesel81 kW (110 PS)FWD or quattro
1.9 TDI1,896 cc, Motorkenndatendiesel85 kW (115 PS)FWD
1.9 TDI1,896 cc, Motorkenndatendiesel85 kW (115 PS)quattro
2.5 TDI2,496 cc, Motorkenndatendiesel110 kW (150 PS)FWD or quattro

Source: Audi A4 B5, de.wikipedia.org.

Performance

VariantPower0 to 62 mph (0 to 100 km/h)Top speed
1.674 kW (101 PS)11.9 to 14.6 s
1.674 kW (101 PS)12.4 to 14.9 s
1.675 kW (102 PS)11.9 s
1.892 kW (125 PS)10.6 to 12.3 s
1.8 T110 kW (150 PS)8.4 to 9.6 s
1.8 T132 kW (180 PS)7.9 s
2.4121 kW (165 PS)8.4 to 10.4 s
2.6110 kW (150 PS)8.7 to 9.8 s
2.8128 kW (174 PS)8.2 s
2.8142 kW (193 PS)7.3 to 9.3 s
S4195 kW (265 PS)5.6 s
1.9 DI55 kW (75 PS)16.1 s
1.9 TDI66 kW (90 PS)13.5 to 14.6 s
1.9 TDI81 kW (110 PS)11.3 to 12.8 s
1.9 TDI85 kW (115 PS)10.5 to 11.9 s
1.9 TDI85 kW (115 PS)10.9 s
2.5 TDI110 kW (150 PS)9 to 10.4 s

Source: Audi A4 B5, de.wikipedia.org.

UK popularity & demand

~5,870 Audi RS4 licensed on UK roads — top 17% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 5,870 Audi RS4 on UK roads, placing it in the top 17% of car models by volume across our fitment database.

That makes Audi RS4 wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Dimensions

Length4,448 to 4,479 mm
Width1,733 to 1,799 mm
Height1,415 to 1,419 mm
Wheelbase2,607 to 2,617 mm
Kerb weight1,170 to 1,620 kg

Source: Audi A4 B5, de.wikipedia.org.

Body styles & production

Body styles5-door Avant (estate/wagon)
Produced1999–2001
Units produced6,030

Factory colours

Imola YellowRabenschwarz MetallicSchwarz MatteMelange Metallic, Melange Beige MetallicBlack, SchwarzMerlin Mica, Merlin PearlAtlantikblau PearlAmulettrot, Amulet RedNemoblau Pearl, Nemo Blue PearlJaspisgruen Metallic, Jaspis Green MetallicJazzbraun MetallicEbony PearlJaipurrot PearlSantorin Blue Mica, Santorinblau PearlJavagruen MetallicIslandgruen MetallicAbsolutrotGoodwoodgruen Pearl, Goodwood Green PearlNimbus Gray Pearl, Nimbusg

Trim levels

Typ 8D

Reliability & owner notes
