Audi RS5 8T/8F side profile — Audi RS5 wheel fitment

Audi RS5 wheel fitment — 8T/8F

By Torque, AIWheelTech vehicle & fitment specialist · 2010–2016
Audi RS5 wheel fitment in one line: The Audi RS5 8T/8F (2010–2016) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~120 Nm. It accepts ~8J–9.5J wheels at ET10–ET31.

Overview

The Audi A5 is a series of compact executive and grand touring coupé cars produced by Audi since June 2007, derived from the Audi A4 saloon and estate models. The first generation (Type 8T) belongs to the B8 family and was unveiled at the Geneva Motor Show in March 2007. It includes coupe, cabriolet, and Sportback variants, with the latter being a five-door liftback with a fastback roofline. This generation marked Audi's return to the compact executive coupé market after a long absence.

Audi RS5 wheel fitment

Start with the hub. The Audi RS5 8T/8F spec table gives the bolt pattern and bore; the second table is the aftermarket window for Audi RS5 wheel fitment.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque120 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front8J–9.5JET10–ET31

Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.

Browse wheels that fit a Audi RS5 →Get them fitted (UK)

UK popularity & demand

~2,560 Audi RS5 licensed on UK roads — top 23% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 2,560 Audi RS5 on UK roads, placing it in the top 23% of car models by volume across our fitment database.

With that many on the road, Audi RS5 wheel fitment is a spec fitters see constantly. We keep it current for that reason.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive
4.2 FSI V84.2L Gasoline Direct Injection (FSI) V8petrol354 hpQuattro
3.0 TFSI V63.0L Supercharged Gasoline Direct Injection (TFSI) V6petrol333 hpQuattro
3.0 TDI CR V63.0L Common Rail Diesel (TDI) V6diesel272 hpQuattro
2.0 TDI CR I42.0L Common Rail Diesel (TDI) Inline-4diesel204 hpQuattro

Performance

VariantPower0–62 mphTop speed
4.2 FSI V8354 hp4.5 s174 mph
3.0 TFSI V6333 hp4.5 s174 mph
2.0 TDI CR I4204 hp5.4 s155 mph
3.0 TDI CR V6272 hp4.9 s155 mph

Dimensions

Length4626 mm
Width1854 mm
Height1372 mm
Wheelbase2751 mm
Kerb weight1500 kg

Body styles & production

Body stylesCoupé, Cabriolet, Sportback
Produced2010–2016

Trim levels

Audi A5S5

Factory colours

Volcano Red MetallicAmethyst Gray MetallicLava Gray PearlOrca Black MetallicGletscherweiss PearlShirazrot MetallicTiefgruen PearlCambridge Green PearlTeak Brown MetallicEisvogelblau MetallicSprint Blue PearlDaytona Gray PearlQuartz Gray MetallicIpanema Brown MetallicDeep Sea Blue PearlGarnet Red PearlSphere Blue MetallicSahara Silver MetallicBrilliant BlackAvussilber Metallic

History & notable variants

The A5 was first unveiled at the Geneva Motor Show in March 2007 alongside its S5 variant. Orders began on the day of unveiling, and deliveries started in June 2007. The model range includes various engine options such as petrol V6 engines (3.2L FSI), diesel V6 engines (3.0L TDI), and smaller turbocharged units introduced later. Notable variants include the RS5 coupé released in 2010, featuring a powerful 4.2L FSI V8 engine.
