Audi S3 wheel fitment — 8P
Audi S3 wheel fitment
Audi S3 wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the Audi S3 8P (2006–2012).
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 57.1 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 7.5J–8.5J | ET27–ET38 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
Overview
The second-generation Audi S3 ('Typ' 8P) is a high-performance variant of the Audi A3, manufactured by German automaker Audi from 2006 to 2012 in Ingolstadt. Built on the Volkswagen Group's PQ35 platform, it features a powerful 2.0L turbocharged FSI engine producing up to 265 PS (261 hp) and is exclusively equipped with quattro all-wheel drive. This generation saw significant improvements over its predecessor, including enhanced performance characteristics, revised chassis tuning, and the introduction of a five-door Sportback variant in 2008.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 1.2 TFSI | VW EA111, 1,197 cc, CBZB | petrol | 77 kW (105 PS) | FWD, 2009 to 2013 |
| 1.4 TFSI | VW EA111, 1,390 cc, CAXC | petrol | 92 kW (125 PS) | FWD, 2007 to 2013 |
| 1.6 | VW EA113, 1,595 cc, BGU, BSE, BSF, CCSA | petrol | 75 kW (102 PS) | FWD, 2003 to 2010 |
| 1.6 FSI | VW EA111, 1,598 cc, BAG, BLF, BLP | petrol | 85 kW (115 PS) | FWD, 2003 to 2007 |
| 1.8 TFSI | VW EA888, 1,798 cc, BYT, BZB, CDAA | petrol | 118 kW (160 PS) | FWD or AWD, 2007 to 2013 |
| 2.0 FSI | VW EA113, (VW EA888), 1,984 cc, AXW, BLR, BLX, BVY | petrol | 110 kW (150 PS) | FWD, 2003 to 2006 |
| 2.0 TFSI | VW EA113, (VW EA888), 1,984 cc | petrol | 147 kW (200 PS) | FWD or AWD, 2004 to 2013 |
| 2.0 TFSI (S3) | VW EA113, (VW EA888), 1,984 cc, BHZ, CDLA | petrol | 195 kW (265 PS) | quattro, 2006 to 2012 |
| 2.5 TFSI (RS3) | VW EA855, 2,480 cc, CEPA | petrol | 250 kW (340 PS) | quattro, 2011 to 2012 |
| 3.2 | VW EA390, 3,189 cc, BDB, BMJ, BUB | petrol | 184 kW (250 PS) | quattro, 2003 to 2009 |
| 1.6 TDI | VW EA189, 1,598 cc, CAYB | diesel | 66 kW (90 PS) | FWD, 2009 to 2012 |
| 1.6 TDI | VW EA189, 1,598 cc, CAYC | diesel | 77 kW (105 PS) | FWD, 2009 to 2013 |
| 1.9 TDI | VW EA188, 1,896 cc, BJB, BKC, BXE, BLS | diesel | 77 kW (105 PS) | FWD, 2003 to 2009 |
| 2.0 TDI | VW EA188, 1,968 cc, BKD | diesel | 103 kW (140 PS) | FWD or quattro, 2003 to 2006 |
| 2.0 TDI | VW EA188, 1,968 cc, BMM | diesel | 103 kW (140 PS) | FWD or quattro, 2005 to 2008 |
| 2.0 TDI | VW EA188, 1,968 cc, BMN, BKQ, BUY | diesel | 125 kW (170 PS) | FWD or quattro, 2006 to 2008 |
| 2.0 TDI | VW EA189, 1,968 cc, CBAB, CFFB | diesel | 103 kW (140 PS) | FWD or quattro, 2008 to 2013 |
| 2.0 TDI | VW EA189, 1,968 cc, CBBB, CFGB | diesel | 125 kW (170 PS) | FWD or quattro, 2008 to 2012 |
Source: Audi A3 8P, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 1.2 TFSI | 77 kW (105 PS) | 10.8 to 12.2 s | 190 to 192 km/h (118 to 119 mph) |
| 1.4 TFSI | 92 kW (125 PS) | 9.3 to 10.7 s | 200 to 203 km/h (124 to 126 mph) |
| 1.6 | 75 kW (102 PS) | 11.7 to 12.9 s | 183 to 185 km/h (114 to 115 mph) |
| 1.6 FSI | 85 kW (115 PS) | 10.9 to 11.1 s | 196 km/h (122 mph) |
| 1.8 TFSI | 118 kW (160 PS) | 7.5 to 8.2 s | 220 to 222 km/h (137 to 138 mph) |
| 2.0 FSI | 110 kW (150 PS) | 8.9 to 9.7 s | 209 to 214 km/h (130 to 133 mph) |
| 2.0 TFSI | 147 kW (200 PS) | 6.6 to 7.4 s | 234 to 238 km/h (145 to 148 mph) |
| 2.0 TFSI (S3) | 195 kW (265 PS) | 5.5 to 5.8 s | 250 km/h (155 mph) |
| 2.5 TFSI (RS3) | 250 kW (340 PS) | 4.6 s | 250 km/h (155 mph) |
| 3.2 | 184 kW (250 PS) | 6.1 to 6.5 s | 250 km/h (155 mph) |
| 1.6 TDI | 66 kW (90 PS) | 12.9 to 13.3 s | 180 km/h (112 mph) |
| 1.6 TDI | 77 kW (105 PS) | 11.4 to 12.2 s | 190 to 194 km/h (118 to 121 mph) |
| 1.9 TDI | 77 kW (105 PS) | 11.1 to 11.7 s | 185 to 194 km/h (115 to 121 mph) |
| 2.0 TDI | 103 kW (140 PS) | 9 to 9.7 s | 205 to 207 km/h (127 to 129 mph) |
| 2.0 TDI | 103 kW (140 PS) | 9 to 9.7 s | 205 to 207 km/h (127 to 129 mph) |
| 2.0 TDI | 125 kW (170 PS) | 7.8 to 8.3 s | 220 to 222 km/h (137 to 138 mph) |
| 2.0 TDI | 103 kW (140 PS) | 8.9 to 9.6 s | 207 to 210 km/h (129 to 130 mph) |
| 2.0 TDI | 125 kW (170 PS) | 7.7 to 8.1 s | 222 to 224 km/h (138 to 139 mph) |
Source: Audi A3 8P, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 36,303 Audi S3 on UK roads, placing it in the top 8% of car models by volume across our fitment database.
That makes Audi S3 wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
History & notable variants
The second-generation Audi S3 was introduced as a high-performance version of the A3, featuring an uprated engine and improved handling. In April 2008, Audi launched the five-door S3 Sportback alongside minor updates to the existing three-door model. The car received positive reception for its performance capabilities but faced criticism due to its relatively high pricing compared to competitors like the BMW 1 Series M Sport.
Dimensions
| Length | 4,203 to 4,302 mm |
| Width | 1,765 to 1,794 mm |
| Height | 1,399 to 1,424 mm |
| Wheelbase | 2,578 mm |
| Kerb weight | 1,530 to 1,590 kg |
Source: Audi A3 8P, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | 3-door hatchback, 5-door hatchback (2008-on) |
| Produced | 2006–2012 |
Trim levels
Factory colours
Reliability & owner notes
- Pros: Powerful engine; Quattro all-wheel drive; Refined handling
- Cons: High price point compared to competitors; Limited availability in North/South America
