Audi S4 B8 Facelift side profile — Audi S4 wheel fitment

Audi S4 wheel fitment — B8 Facelift

By Torque, AIWheelTech vehicle & fitment specialist · 2012–2016
Audi S4 wheel fitment in one line: The Audi S4 B8 Facelift (2012–2016) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~140 Nm. It accepts ~7.5J–8.5J wheels at ET24–ET45.

Overview

The Audi S4 is the high-performance variant of Audi's compact executive car, the Audi A4. Starting with the B5 platform in 1997, each generation has been based on its respective A4 model, evolving alongside it. The S4 features a longitudinally mounted engine and comes standard with Audi’s quattro all-wheel drive system using a Torsen-based center differential. It distinguishes itself from regular A4 models through enhanced performance characteristics such as upgraded brakes, firmer suspension, larger wheels, distinctive styling cues, and powerful engines. In markets without the higher-performance RS 4 variant, the S4 serves as Audi's top-tier offering in the compact executive car segment.

Audi S4 wheel fitment

Start with the hub. The Audi S4 B8 Facelift spec table gives the bolt pattern and bore; the second table is the aftermarket window for Audi S4 wheel fitment.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque140 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front7.5J–8.5JET24–ET45

Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.

Browse wheels that fit a Audi S4 →Get them fitted (UK)

UK popularity & demand

~8,899 Audi S4 licensed on UK roads — top 15% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 8,899 Audi S4 on UK roads, placing it in the top 15% of car models by volume across our fitment database.

A parc that size is why Audi S4 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive, years
1.8 TFSIVW EA888, 1,798 ccpetrol88 kW (120 PS)FWD, 2008 to 2015
1.8 TFSIVW EA888, 1,798 ccpetrol118 kW (160 PS)FWD or AWD, 2007 to 2011
1.8 TFSIVW EA888, 1,798 ccpetrol125 kW (170 PS)FWD or AWD, 2011 to 2015
2.0 TFSI flexibleVW EA888, 1,984 ccpetrol132 kW (180 PS)FWD or AWD, 2009 to 2015
2.0 TFSIVW EA888, 1,984 ccpetrol132 kW (180 PS)FWD or AWD, 2008 to 2011
2.0 TFSIVW EA888, 1,984 ccpetrol155 kW (211 PS)FWD or AWD, 2008 to 2013
2.0 TFSIVW EA888, 1,984 ccpetrol165 kW (225 PS)FWD or AWD, 2013 to 2015
3.0 TFSIVW EA837, 2,995 ccpetrol200 kW (272 PS)quattro, 2012 to 2015
3.0 TFSI (S4)VW EA837, 2,995 ccpetrol245 kW (333 PS)quattro, 2008 to 2015
3.2 FSIVW EA837, 3,197 ccpetrol195 kW (265 PS)FWD or AWD, 2007 to 2011
4.2 FSI (RS4)VW EA824, 4,163 ccpetrol331 kW (450 PS)AWD, 2012 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel88 kW (120 PS)FWD, 2008 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel100 kW (136 PS)FWD, 2009 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel105 kW (143 PS)FWD or AWD, 2007 to 2013
2.0 TDIVW EA288, 1,968 ccdiesel110 kW (150 PS)FWD or AWD, 2013 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel120 kW (163 PS)FWD, 2011 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel125 kW (170 PS)FWD or AWD, 2008 to 2011
2.0 TDIVW EA189, 1,968 ccdiesel130 kW (177 PS)FWD or AWD, 2011 to 2015
2.0 TDIVW EA288, 1,968 ccdiesel140 kW (190 PS)FWD or AWD, 2014 to 2015
2.7 TDIVW EA896, 2,698 ccdiesel140 kW (190 PS)FWD, 2007 to 2011
3.0 TDIVW EA896G2, 2,967 ccdiesel150 kW (204 PS)FWD, 2011 to 2015
3.0 TDIVW EA896, 2,967 ccdiesel176 kW (240 PS)quattro, 2007 to 2011
3.0 TDIVW EA896G2, 2,967 ccdiesel180 kW (245 PS)quattro, 2011 to 2015

Source: Audi A4 B8, de.wikipedia.org.

Performance

VariantPower0 to 62 mph (0 to 100 km/h)Top speed
1.8 TFSI88 kW (120 PS)10.5 to 10.8 s
1.8 TFSI118 kW (160 PS)8.6 to 8.9 s
1.8 TFSI125 kW (170 PS)7.9 to 8.3 s
2.0 TFSI flexible132 kW (180 PS)7.7 to 8.1 s
2.0 TFSI132 kW (180 PS)7.7 to 8.6 s
2.0 TFSI155 kW (211 PS)6.5 to 7.4 s
2.0 TFSI165 kW (225 PS)6.4 to 6.9 s
3.0 TFSI200 kW (272 PS)5.9 to 6.1 s
3.0 TFSI (S4)245 kW (333 PS)5 to 5.4 s
3.2 FSI195 kW (265 PS)6.2 to 6.6 s
4.2 FSI (RS4)331 kW (450 PS)4.7 s
2.0 TDI88 kW (120 PS)10.5 to 11.2 s
2.0 TDI100 kW (136 PS)9.3 to 9.8 s
2.0 TDI105 kW (143 PS)9.1 to 10.3 s
2.0 TDI110 kW (150 PS)9.1 to 9.7 s
2.0 TDI120 kW (163 PS)8.3 to 8.7 s
2.0 TDI125 kW (170 PS)8.3 to 8.9 s
2.0 TDI130 kW (177 PS)7.8 to 8.4 s
2.0 TDI140 kW (190 PS)7.3 to 8.3 s
2.7 TDI140 kW (190 PS)7.7 to 8.2 s
3.0 TDI150 kW (204 PS)7.1 to 7.9 s
3.0 TDI176 kW (240 PS)6.1 to 6.6 s
3.0 TDI180 kW (245 PS)5.9 to 6.3 s

Source: Audi A4 B8, de.wikipedia.org.

Dimensions

Length4,699 to 4,761 mm
Width1,826 to 1,850 mm
Height1,406 to 1,495 mm
Wheelbase2,805 to 2,813 mm
Kerb weight1,705 to 1,825 kg

Source: Audi A4 B8, de.wikipedia.org; EU type-approval data (EEA).

Body styles & production

Body styles4-door saloon/sedan, 5-door estate/wagon (Avant)
Produced2012–2016

Trim levels

B5

Factory colours

Ibis WhiteDaytona Gray PearlMoonlight Blue PearlMonsoon Gray MetallicGlacier White Pearl TricoatBrilliant BlackMythos Black MetallicFlorett Silver MetallicChronos Grey MetallicPhantom Black PearlNavarra Blue MetallicGlacier White TricoatIce Silver MetallicPure WhiteNogaro Blue PearlImola YellowMisano RedNardo GrayQuantum GreySepang Blue

History & notable variants

The B5 generation of the Audi S4 was introduced alongside a facelifted A4 line-up in October 1997. It featured a powerful 2.7-liter twin-turbo V6 engine and continued to be produced until September 2001, with sales extending into 2002 in North America. Notable for its performance capabilities, the B5 S4 was also successful in motorsports, particularly in the SpeedVision World Challenge where it won the GT title in 2001.
