Audi S4 B8 side profile — Audi S4 wheel fitment

Audi S4 wheel fitment — B8

By Torque, AIWheelTech vehicle & fitment specialist · 2009–2012
Quick answer on Audi S4 wheel fitment: The Audi S4 B8 (2009–2012) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~140 Nm. It accepts ~7.5J–8.5J wheels at ET24–ET45.

Audi S4 wheel fitment

Audi S4 wheel fitment for the Audi S4 B8 (2009–2012): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque140 Nm
Seat typeradius
Factory setupsquare
TPMSindirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front7.5J–8.5JET24–ET45

Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.

Browse wheels that fit a Audi S4 →Get them fitted (UK)

UK popularity & demand

~8,899 Audi S4 licensed on UK roads — top 15% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 8,899 Audi S4 on UK roads, placing it in the top 15% of car models by volume across our fitment database.

A parc that size is why Audi S4 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Overview

The Audi S4 is the high-performance variant of Audi's compact executive car, the Audi A4. The original S4 was built from 1991 to 1994 as a performance-oriented version of the Audi 100 sedan. Since then, all subsequent generations have been based on the Audi A4 platform, evolving alongside it. Each generation has featured longitudinally oriented front-mounted engines and Audi's quattro all-wheel drive system with a Torsen-based center differential. The S4 is distinguished by its more powerful engine, upgraded brakes, firmer suspension, larger wheels, distinctive styling cues, and exclusive badging compared to standard A4 models. It competes in the compact executive car segment against vehicles like BMW's M3 series and Mercedes-Benz C-Class AMG variants.

Dimensions

Length4,699 to 4,761 mm
Width1,826 to 1,850 mm
Height1,406 to 1,495 mm
Wheelbase2,805 to 2,813 mm
Kerb weight1,735 to 1,825 kg

Source: Audi A4 B8, de.wikipedia.org; EU type-approval data (EEA).

Body styles & production

Body styles4-door saloon/sedan, 5-door estate/wagon (Avant)
Produced2009–2012

Engines & drivetrain

VariantEngineFuelPowerDrive, years
1.8 TFSIVW EA888, 1,798 ccpetrol88 kW (120 PS)FWD, 2008 to 2015
1.8 TFSIVW EA888, 1,798 ccpetrol118 kW (160 PS)FWD or AWD, 2007 to 2011
1.8 TFSIVW EA888, 1,798 ccpetrol125 kW (170 PS)FWD or AWD, 2011 to 2015
2.0 TFSI flexibleVW EA888, 1,984 ccpetrol132 kW (180 PS)FWD or AWD, 2009 to 2015
2.0 TFSIVW EA888, 1,984 ccpetrol132 kW (180 PS)FWD or AWD, 2008 to 2011
2.0 TFSIVW EA888, 1,984 ccpetrol155 kW (211 PS)FWD or AWD, 2008 to 2013
2.0 TFSIVW EA888, 1,984 ccpetrol165 kW (225 PS)FWD or AWD, 2013 to 2015
3.0 TFSIVW EA837, 2,995 ccpetrol200 kW (272 PS)quattro, 2012 to 2015
3.0 TFSI (S4)VW EA837, 2,995 ccpetrol245 kW (333 PS)quattro, 2008 to 2015
3.2 FSIVW EA837, 3,197 ccpetrol195 kW (265 PS)FWD or AWD, 2007 to 2011
4.2 FSI (RS4)VW EA824, 4,163 ccpetrol331 kW (450 PS)AWD, 2012 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel88 kW (120 PS)FWD, 2008 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel100 kW (136 PS)FWD, 2009 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel105 kW (143 PS)FWD or AWD, 2007 to 2013
2.0 TDIVW EA288, 1,968 ccdiesel110 kW (150 PS)FWD or AWD, 2013 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel120 kW (163 PS)FWD, 2011 to 2015
2.0 TDIVW EA189, 1,968 ccdiesel125 kW (170 PS)FWD or AWD, 2008 to 2011
2.0 TDIVW EA189, 1,968 ccdiesel130 kW (177 PS)FWD or AWD, 2011 to 2015
2.0 TDIVW EA288, 1,968 ccdiesel140 kW (190 PS)FWD or AWD, 2014 to 2015
2.7 TDIVW EA896, 2,698 ccdiesel140 kW (190 PS)FWD, 2007 to 2011
3.0 TDIVW EA896G2, 2,967 ccdiesel150 kW (204 PS)FWD, 2011 to 2015
3.0 TDIVW EA896, 2,967 ccdiesel176 kW (240 PS)quattro, 2007 to 2011
3.0 TDIVW EA896G2, 2,967 ccdiesel180 kW (245 PS)quattro, 2011 to 2015

Source: Audi A4 B8, de.wikipedia.org.

Performance

VariantPower0 to 62 mph (0 to 100 km/h)Top speed
1.8 TFSI88 kW (120 PS)10.5 to 10.8 s
1.8 TFSI118 kW (160 PS)8.6 to 8.9 s
1.8 TFSI125 kW (170 PS)7.9 to 8.3 s
2.0 TFSI flexible132 kW (180 PS)7.7 to 8.1 s
2.0 TFSI132 kW (180 PS)7.7 to 8.6 s
2.0 TFSI155 kW (211 PS)6.5 to 7.4 s
2.0 TFSI165 kW (225 PS)6.4 to 6.9 s
3.0 TFSI200 kW (272 PS)5.9 to 6.1 s
3.0 TFSI (S4)245 kW (333 PS)5 to 5.4 s
3.2 FSI195 kW (265 PS)6.2 to 6.6 s
4.2 FSI (RS4)331 kW (450 PS)4.7 s
2.0 TDI88 kW (120 PS)10.5 to 11.2 s
2.0 TDI100 kW (136 PS)9.3 to 9.8 s
2.0 TDI105 kW (143 PS)9.1 to 10.3 s
2.0 TDI110 kW (150 PS)9.1 to 9.7 s
2.0 TDI120 kW (163 PS)8.3 to 8.7 s
2.0 TDI125 kW (170 PS)8.3 to 8.9 s
2.0 TDI130 kW (177 PS)7.8 to 8.4 s
2.0 TDI140 kW (190 PS)7.3 to 8.3 s
2.7 TDI140 kW (190 PS)7.7 to 8.2 s
3.0 TDI150 kW (204 PS)7.1 to 7.9 s
3.0 TDI176 kW (240 PS)6.1 to 6.6 s
3.0 TDI180 kW (245 PS)5.9 to 6.3 s

Source: Audi A4 B8, de.wikipedia.org.

Trim levels

Premium PlusSport

Factory colours

Ibis WhiteDaytona Gray PearlMoonlight Blue PearlMonsoon Gray MetallicGlacier White Pearl TricoatBrilliant BlackMythos Black MetallicFlorett Silver MetallicChronos Grey MetallicPhantom Black PearlNavarra Blue MetallicGlacier White TricoatIce Silver MetallicPure WhiteNogaro Blue PearlImola YellowMisano RedNardo GrayQuantum GreySepang Blue Pearl

History & notable variants

The B8 generation of Audi S4 was introduced with a supercharged 3.0-liter V6 TFSI engine, competing directly with the BMW 3 Series (E90) and Mercedes-Benz C-Class (W204). The current B9 generation uses a turbocharged 3.0-liter V6 TFSI engine and faces competition from models such as the BMW M340i xDrive and Mercedes-AMG C43 4MATIC. All versions of the S4 have been manufactured at Audi's plant in Ingolstadt, Germany.
