Audi S8 wheel fitment — D3
Overview
The Audi S8 D3 is a full-size luxury car produced by Audi AG from 2006 to 2010, manufactured at the Neckarsulm plant. It is based on the Volkswagen Group D platform and features Audi's quattro all-wheel drive system. The second generation of the S8 series, it was powered by a modified V10 engine detuned for better fuel efficiency compared to its Lamborghini Gallardo counterpart.
Audi S8 wheel fitment
Start with the hub. The Audi S8 D3 spec table gives the bolt pattern and bore; the second table is the aftermarket window for Audi S8 wheel fitment.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 57.1 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 9J–10J | ET27–ET48 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 949 Audi S8 on UK roads, placing it in the top 31% of car models by volume across our fitment database.
A parc that size is why Audi S8 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 2.8 FSI | 2,773 cc | petrol | 154 kW (210 PS) | FWD, 2007 to 2010 |
| 3.0 (L) | 2,976 cc | 162 kW (220 PS) | FWD, 2003 to 2005 | |
| 3.2 FSI (L) | 3,123 cc | petrol | 191 kW (260 PS) | FWD or AWD, 2005 to 2010 |
| 3.7 | 3,697 cc | 206 kW (280 PS) | quattro, 2002 to 2006 | |
| 4.2 (L) | 4,172 cc | 246 kW (335 PS) | quattro, 2002 to 2006 | |
| 4.2 FSI (L) | 4,163 cc | petrol | 257 kW (350 PS) | quattro, 2006 to 2010 |
| S8 | 5,204 cc | 331 kW (450 PS) | quattro, 2006 to 2010 | |
| 6.0 W12 (L) | 5,998 cc | 331 kW (450 PS) | quattro, 2003 to 2010 | |
| 3.0 TDI (L) | 2,967 cc | diesel | 171 kW (233 PS) | quattro, 2003 to 2010 |
| 4.0 TDI (L) | 3,936 cc | diesel | 202 kW (275 PS) | quattro, 2003 to 2005 |
| 4.2 TDI (L) | 4,134 cc | diesel | 240 kW (326 PS) | quattro, 2005 to 2010 |
Source: Audi A8 D3, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 2.8 FSI | 154 kW (210 PS) | 8 s | |
| 3.0 (L) | 162 kW (220 PS) | 7.9 s | |
| 3.2 FSI (L) | 191 kW (260 PS) | 7.7 s | |
| 3.7 | 206 kW (280 PS) | 7.3 s | |
| 4.2 (L) | 246 kW (335 PS) | 6.3 s | |
| 4.2 FSI (L) | 257 kW (350 PS) | 6.1 s | |
| S8 | 331 kW (450 PS) | 5.1 s | |
| 6.0 W12 (L) | 331 kW (450 PS) | 5.1 s | |
| 3.0 TDI (L) | 171 kW (233 PS) | 7.8 s | |
| 4.0 TDI (L) | 202 kW (275 PS) | 6.7 s | |
| 4.2 TDI (L) | 240 kW (326 PS) | 5.9 s |
Source: Audi A8 D3, de.wikipedia.org.
Dimensions
| Length | 5,062 to 5,192 mm |
| Width | 1,894 mm |
| Height | 1,424 to 1,445 mm |
| Wheelbase | 2,944 to 3,074 mm |
| Kerb weight | 1,670 to 1,995 kg |
Source: Audi A8 D3, de.wikipedia.org.
Body styles & production
| Body styles | Limousine |
| Produced | 2006–2010 |
Trim levels
Factory colours
History & notable variants
The Audi S8 (D3) was introduced in 2006 and marked a significant shift with its powerful yet efficient V10 engine. It received no major facelifts during its production run but was noted for its performance capabilities and luxury features, setting the stage for future iterations of the model.
Reliability & owner notes
- Pros: Powerful V10 engine; Efficient fuel consumption for its class; Audi's quattro all-wheel drive system
- Cons: Heavier than previous generation; Limited production run
