Audi S8 wheel fitment — D4 Facelift
Audi S8 wheel fitment
Audi S8 wheel fitment for the Audi S8 D4 Facelift (2014–2018): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | radius |
| Factory setup | square |
| TPMS | indirect |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 9J–10J | ET22–ET42 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 949 Audi S8 on UK roads, placing it in the top 31% of car models by volume across our fitment database.
A parc that size is why Audi S8 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Overview
The Audi S8 is a full-size luxury car produced by German automaker Audi AG, manufactured by Audi Sport GmbH at the Neckarsulm plant as part of Audi's high-performance S model range. It is the high-performance version of the Audi A8 and comes standard with quattro all-wheel drive. The first three generations were offered only in a short-wheelbase variant, while the fourth generation introduced both short and long-wheelbase options.
Dimensions
| Length | 5,135 to 5,267 mm |
| Width | 1,949 mm |
| Height | 1,458 to 1,471 mm |
| Wheelbase | 2,990 to 3,122 mm |
| Kerb weight | 1,870 to 2,170 kg |
Source: Audi A8 D4, de.wikipedia.org.
Body styles & production
| Body styles | Limousine |
| Produced | 2014–2018 |
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| hybrid (L) | VW EA888, 1,984 cc, CHJA | petrol | 180 kW (245 PS) | FWD, 2012 to 2015 |
| 3.0 TDI | VW EA896G2, 2,967 cc, CLAB | diesel | 150 kW (204 PS) | FWD, 2011 to 2013 |
| 3.0 TDI (L) | VW EA896G2, 2,967 cc, CDTA | diesel | 184 kW (250 PS) | AWD, 2010 to 2013 |
| 3.0 TDI (L) | VW EA896G2, 2,967 cc, CTBA | diesel | 190 kW (258 PS) | AWD, 2013 to 2015 |
| 3.0 TDI (L) | VW EA897 evo, 2,967 cc, CTBD | diesel | 193 kW (262 PS) | AWD, 2015 to 2017 |
| 3.0 TDI ultra | VW EA897 evo, 2,967 cc, CTBD | diesel | 193 kW (262 PS) | AWD, 2015 to 2017 |
| 4.2 TDI (L) | VW EA898, 4,134 cc, CDSB | diesel | 258 kW (351 PS) | AWD, 2009 to 2013 |
| 4.2 TDI (L) | VW EA898, 4,134 cc, CTEC | diesel | 283 kW (385 PS) | AWD, 2013 to 2017 |
Source: Audi A8 D4, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| hybrid (L) | 180 kW (245 PS) | 7.7 to 7.9 s | |
| 3.0 TDI | 150 kW (204 PS) | 7.9 s | |
| 3.0 TDI (L) | 184 kW (250 PS) | 6.1 to 6.2 s | |
| 3.0 TDI (L) | 190 kW (258 PS) | 5.9 to 6.1 s | |
| 3.0 TDI (L) | 193 kW (262 PS) | 5.9 to 6.1 s | |
| 3.0 TDI ultra | 193 kW (262 PS) | 5.9 s | |
| 4.2 TDI (L) | 258 kW (351 PS) | 5.5 to 5.6 s | |
| 4.2 TDI (L) | 283 kW (385 PS) | 4.7 to 4.9 s |
Source: Audi A8 D4, de.wikipedia.org.
Trim levels
Factory colours
History & notable variants
The D2 generation was produced from 1996 to 2003, powered by a 4.2L V8 engine with significant power upgrades over its production years. The D3 generation followed from 2006 to 2010 and featured a modified Lamborghini V10 engine for increased fuel efficiency. The D4 generation (2012-2018) saw mid-facelifts, including the introduction of the S8 Plus variant in 2016 with enhanced performance capabilities. The D5 generation began production in 2019 and introduced a mild hybrid system.
Reliability & owner notes
- Pros: High-performance capabilities, luxurious interior, advanced technology features
- Cons: Expensive price point, high fuel consumption
