BMW 4 Series Gran Coupe wheel fitment — F36 LCI

By Torque, AIWheelTech vehicle & fitment specialist · 2017–2021
BMW 4 Series Gran Coupe wheel fitment at a glance — The BMW 4 Series Gran Coupe F36 LCI (2017–2021) uses a 5x120 bolt pattern, 72.6 mm centre bore, M14 x 1.25 bolts torqued to ~140 Nm. It accepts ~7J–8J wheels at ET18–ET27 front; staggered setups run 8J–9.5J rear (ET29–ET45).

Overview

The BMW 4 Series Gran Coupe F36 is part of the first generation (F32/F33/F36) of compact executive cars manufactured by BMW from 2014 to 2020. It was introduced as a successor to the E92/E93 coupé/convertible models of the fifth-generation 3 Series range and shares many features with the F30 3 Series. The Gran Coupe is available in both rear-wheel drive (RWD) and all-wheel drive (xDrive) configurations, powered by turbocharged petrol and diesel engines.

BMW 4 Series Gran Coupe wheel fitment

BMW 4 Series Gran Coupe wheel fitment for the BMW 4 Series Gran Coupe F36 LCI (2017–2021): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x120
Centre bore72.6 mm
Bolt / threadM14 x 1.25 (bolts)
Wheel-bolt torque140 Nm
Seat typetapered
Factory setupstaggered
TPMSdirect
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front7J–8JET18–ET27
Rear (staggered)8J–9.5JET29–ET45

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a BMW 4 Series Gran Coupe →Get them fitted (UK)

UK popularity & demand

~113,829 BMW 4 Series Gran Coupe range licensed on UK roads — top 3% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 113,829 BMW 4 Series Gran Coupe range on UK roads, placing it in the top 3% of car models by volume across our fitment database.

That makes BMW 4 Series Gran Coupe wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive
M440i xDrive3.0L B58 turbo petrol V6petrol374 hpxDrive
330i2.0L B48 turbo petrolpetrol258 hpRWD
320d2.0L B47 turbo dieseldiesel190 hpRWD
320d xDrive2.0L B47 turbo dieseldiesel190 hpxDrive
330d2.0L B47 turbo dieseldiesel190 hpRWD
320i2.0L B48 turbo petrolpetrol184 hpRWD
320i xDrive2.0L B48 turbo petrolpetrol184 hpxDrive
318i1.5L B38 turbo petrolpetrol140 hpRWD

Performance

VariantPower0–62 mphTop speed
318i140 hp7.9 s139 mph
320i184 hp7.1 s150 mph
320d190 hp7.4 s148 mph
320i xDrive184 hp7.5 s149 mph
320d xDrive190 hp7.5 s148 mph
330i258 hp5.1 s155 mph
330d190 hp6.8 s148 mph
M440i xDrive374 hp4.3 s155 mph

Body styles & production

Body stylesGran Coupé
Produced2017–2021

Trim levels

M SportLuxury Line

Factory colours

Alpinweiss Iii SolidCarbonschwarz MetallicBlacksapphire MetallicKalaharibeige Metallic

History & notable variants

The first generation BMW 4 Series was launched as a separate series from the 2-door models of the 3 Series. It includes coupé, convertible, and Gran Coupé body styles. The F36 model code for the Gran Coupe was introduced in 2014 and produced until 2020. Notable is the introduction of high-performance M4 variants (F82/F83) in early 2014.

Reliability & owner notes
