BMW 4 Series F32/F33 side profile — BMW 4 Series wheel fitment

BMW 4 Series wheel fitment — F32/F33

By Torque, AIWheelTech vehicle & fitment specialist · 2013–2017
If you only need the numbers for BMW 4 Series wheel fitment: The BMW 4 Series F32/F33 (2013–2017) uses a 5x120 bolt pattern, 72.6 mm centre bore, M14 x 1.25 bolts torqued to ~140 Nm. It accepts ~6.5J–8.5J wheels at ET24–ET45 front; staggered setups run 8J–10J rear (ET33–ET50).

BMW 4 Series wheel fitment

BMW 4 Series wheel fitment for the BMW 4 Series F32/F33 (2013–2017): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x120
Centre bore72.6 mm
Bolt / threadM14 x 1.25 (bolts)
Wheel-bolt torque140 Nm
Seat typetapered
Factory setupstaggered
TPMSdirect
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6.5J–8.5JET24–ET45
Rear (staggered)8J–10JET33–ET50

As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a BMW 4 Series →Get them fitted (UK)

UK popularity & demand

~113,829 BMW 4 Series licensed on UK roads — top 3% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 113,829 BMW 4 Series on UK roads, placing it in the top 3% of car models by volume across our fitment database.

That makes BMW 4 Series wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Overview

The BMW 4 Series is a range of compact executive cars manufactured by BMW since 2013. The first generation (F32/F33/F36) was produced from 2014 to 2020, featuring coupé, convertible, and Gran Coupé body styles. It succeeded the E92/E93 models of the fifth-generation BMW 3 Series range and shares many features with the F30 3 Series. The engines available include turbocharged inline-3, inline-4, and inline-6 petrol or diesel units.

Dimensions

Length4,638 to 4,689 mm
Width1,825 to 1,870 mm
Height1,377 to 1,392 mm
Wheelbase2,810 mm
Kerb weight1,450 to 1,975 kg

Source: BMW F32, de.wikipedia.org; EU type-approval data (EEA).

Body styles & production

Body styles2-door coupé (F32), 2-door convertible (F33), 5-door liftback/fastback sedan (F36)
Produced2013–2017

Engines & drivetrain

VariantEngineFuelPowerDrive, years
420iN20B20, 1,997 ccpetrol135 kW (184 PS)RWD or xDrive, 2013 to 2016
420iB48B20, 1,998 ccpetrol135 kW (184 PS)RWD or xDrive, 2016 to 2021
428iN20B20, 1,997 ccpetrol180 kW (245 PS)RWD or xDrive, 2013 to 2016
430iB48B20, 1,998 ccpetrol185 kW (252 PS)RWD or xDrive, 2016 to 2021
435iN55B30, 2,979 ccpetrol225 kW (306 PS)RWD or xDrive, 2013 to 2016
440iB58B30, 2,998 ccpetrol240 kW (326 PS)RWD or xDrive, 2016 to 2021
M4S55B30, 2,979 ccpetrol317 kW (431 PS)RWD, 2014 to 2019
M4 CompetitionS55B30, 2,979 ccpetrol331 kW (450 PS)RWD, 2016 to 2020
M4 CSS55B30, 2,979 ccpetrol338 kW (460 PS)RWD, 2017 to 2018
M4 GTSS55B30, 2,979 ccpetrol368 kW (500 PS)RWD, 2016 to 2017
418dN47D20, 1,995 ccdiesel105 kW (143 PS)RWD, 2014 to 2015
418dB47D20, 1,995 ccdiesel110 kW (150 PS)RWD, 2015 to 2017
420dN47D20, 1,995 ccdiesel135 kW (184 PS)RWD or xDrive, 2013 to 2015
420dB47D20, 1,995 ccdiesel140 kW (190 PS)RWD or xDrive, 2015 to 2020
425dN47D20, 1,995 ccdiesel160 kW (218 PS)RWD, 2014 to 2016
425dB47D20, 1,995 ccdiesel165 kW (224 PS)RWD, 2016 to 2017
430dN57D30, 2,993 ccdiesel190 kW (258 PS)RWD or xDrive, 2013 to 2020
435dN57D30, 2,993 ccdiesel230 kW (313 PS)xDrive, 2013 to 2020

Source: BMW F32, de.wikipedia.org.

Trim levels

F32F33F36

Factory colours

Alpine White IIIImola RedCarbon Black MetallicBlack Sapphire MetallicKalahari Beige MetallicFrozen Silver Metallic MatteFrozen Gray Metallic MatteFrozen Bronze Metallic MatteFrozen Black Metallic MatteJet BlackSilverstone II MetallicMelbourne Red MetallicGlaciersilber II MetallicImperial Blue MetallicOrion Silver MetallicMineral White PearlDark Shadow MetallicMidnight Blue MetallicMineralgrau MetallicLiquid Blue Metallic

History & notable variants

The first generation was introduced in January 2013 as a concept car at the North American International Auto Show in Detroit. It was produced alongside the F30 3 Series and featured high-performance variants like the F82/F83 M4, powered by the S55 turbocharged straight-six engine. The second generation (G22/G23/G26) launched in June 2020 with significant design changes to distinguish it from the 3 Series.

Reliability & owner notes
