BMW 5 Series wheel fitment — III E34
Overview
The BMW E34 is the third generation of the BMW 5 Series produced from November 1987 to June 1996. Initially launched as a saloon in January 1988, it later included a station wagon variant starting September 1992. The E34 was built at Dingolfing and Rosslyn plants for Germany and South Africa respectively, with some models assembled in Thailand. This generation marked the introduction of all-wheel drive (525iX) and V8 engines to the series, alongside advanced features like stability control and adjustable damping systems.
History & notable variants
Development began in 1981 under Ercole Spada's initial design proposal and was finalized by J Mays for production. The E34 debuted at the end of 1987 with a focus on aerodynamics (drag coefficient of 0.30). Notable variants include the BMW M5, powered by the S38 engine in both sedan and wagon forms. Special editions like the Alpina B10 series offered enhanced performance options.
BMW 5 Series wheel fitment
Everything below is what the fit-check uses for BMW 5 Series wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the BMW 5 Series III (E34).
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 72.6 mm |
| Bolt / thread | M12 x 1.5 (bolts) |
| Wheel-bolt torque | 115 Nm |
| Seat type | tapered |
| Factory setup | square |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 7J–7J | ET15–ET25 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 518i | 1,796 cc, M40B18 | petrol | 83 kW (113 PS) | 1989 to 1994 |
| 518i | 1,796 cc, M43B18 | petrol | 85 kW (115 PS) | 1994 to 1996 |
| 518g | 1,796 cc, M43B18 | petrol | 74 kW (100 PS) | 1995 to 1996 |
| 520i | 1,990 cc, M20B20 | petrol | 95 kW (129 PS) | 1988 to 1990 |
| 520i | 1,991 cc, M50B20 | petrol | 110 kW (150 PS) | 1990 to 1992 |
| 520i | 1,991 cc, M50B20(TÜ) | petrol | 110 kW (150 PS) | 1992 to 1996 |
| 525i | 2,494 cc, M20B25 | petrol | 125 kW (170 PS) | 1988 to 1990 |
| 525i | 2,494 cc, M50B25 | petrol | 141 kW (192 PS) | 1990 to 1992 |
| 525i | 2,494 cc, M50B25(TÜ) | petrol | 141 kW (192 PS) | 1992 to 1996 |
| 525iX | 2,494 cc, M50B25 | petrol | 141 kW (192 PS) | 1991 to 1992 |
| 525iX | 2,494 cc, M50B25(TÜ) | petrol | 141 kW (192 PS) | 1992 to 1996 |
| 530i | 2,986 cc, M30B30 | petrol | 138 kW (188 PS) | 1988 to 1990 |
| 530i | 2,997 cc, M60B30 | petrol | 160 kW (218 PS) | 1992 to 1996 |
| 535i | 3,430 cc, M30B35 | petrol | 155 kW (211 PS) | 1988 to 1992 |
| 540i | 3,982 cc, M60B40 | petrol | 210 kW (286 PS) | 1992 to 1996 |
| M5 | 3,535 cc, S38B36 | petrol | 232 kW (315 PS) | 1988 to 1992 |
| M5 | 3,795 cc, S38B38 | petrol | 250 kW (340 PS) | 1992 to 1995 |
| 524td | 2,443 cc, M21D24 | diesel | 85 kW (115 PS) | 1988 to 1991 |
| 525td | 2,498 cc, M51D25 | diesel | 85 kW (115 PS) | 1993 to 1996 |
| 525tds | 2,498 cc, M51D25 | diesel | 105 kW (143 PS) | 1991 to 1996 |
| B10 3.0 Allrad | 2,997 cc | diesel | 170 kW (231 PS) | 1993 to 1996 |
| B10 3.5/1 | 3,430 cc | diesel | 187 kW (254 PS) | 1988 to 1992 |
| B10 4.0 | 3,982 cc | diesel | 232 kW (315 PS) | 1993 to 1995 |
| B10 4.6 | 4,619 cc | diesel | 250 kW (340 PS) | 1994 to 1996 |
| B10 Biturbo | 3,430 cc | diesel | 265 kW (360 PS) | 1989 to 1994 |
Source: BMW E34, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 518i | 83 kW (113 PS) | 12.4 s | 190 to 194 km/h (118 to 121 mph) |
| 518i | 85 kW (115 PS) | 12.3 s | 192 to 198 km/h (119 to 123 mph) |
| 518g | 74 kW (100 PS) | 16.2 s | 183 to 192 km/h (114 to 119 mph) |
| 520i | 95 kW (129 PS) | 11.9 s | 198 to 203 km/h (123 to 126 mph) |
| 520i | 110 kW (150 PS) | 10.6 s | 202 to 211 km/h (126 to 131 mph) |
| 520i | 110 kW (150 PS) | 10.6 s | 202 to 211 km/h (126 to 131 mph) |
| 525i | 125 kW (170 PS) | 9.5 s | 217 to 221 km/h (135 to 137 mph) |
| 525i | 141 kW (192 PS) | 8.6 s | 218 to 230 km/h (135 to 143 mph) |
| 525i | 141 kW (192 PS) | 8.6 s | 218 to 230 km/h (135 to 143 mph) |
| 525iX | 141 kW (192 PS) | 9.5 s | 212 to 220 km/h (132 to 137 mph) |
| 525iX | 141 kW (192 PS) | 9.5 s | 212 to 220 km/h (132 to 137 mph) |
| 530i | 138 kW (188 PS) | 8.6 s | 224 to 227 km/h (139 to 141 mph) |
| 530i | 160 kW (218 PS) | 7.7 s | 225 to 235 km/h (140 to 146 mph) |
| 535i | 155 kW (211 PS) | 7.7 s | 231 to 235 km/h (144 to 146 mph) |
| 540i | 210 kW (286 PS) | 6.3 s | 240 km/h (149 mph) |
| M5 | 232 kW (315 PS) | 6.3 s | 250 km/h (155 mph) |
| M5 | 250 kW (340 PS) | 5.9 s | 250 km/h (155 mph) |
| 524td | 85 kW (115 PS) | 12.9 s | 190 to 192 km/h (118 to 119 mph) |
| 525td | 85 kW (115 PS) | 12.9 s | 183 to 194 km/h (114 to 121 mph) |
| 525tds | 105 kW (143 PS) | 11 s | 200 to 207 km/h (124 to 129 mph) |
| B10 3.0 Allrad | 170 kW (231 PS) | 235 km/h (146 mph) | |
| B10 3.5/1 | 187 kW (254 PS) | 252 km/h (157 mph) | |
| B10 4.0 | 232 kW (315 PS) | 268 km/h (167 mph) | |
| B10 4.6 | 250 kW (340 PS) | 277 km/h (172 mph) | |
| B10 Biturbo | 265 kW (360 PS) | 291 km/h (181 mph) |
Source: BMW E34, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 196,854 BMW 5 Series on UK roads, placing it in the top 2% of car models by volume across our fitment database.
A parc that size is why BMW 5 Series wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 4,720 mm |
| Width | 1,751 mm |
| Height | 1,412 to 1,421 mm |
| Wheelbase | 2,761 mm |
| Kerb weight | 1,360 to 1,685 kg |
Source: BMW E34, de.wikipedia.org.
Body styles & production
| Body styles | 4-door saloon, 5-door estate (Touring) |
| Produced | 1987–1996 |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Advanced features like stability control and adjustable damping systems; Introduction of all-wheel drive and V8 engines
- Cons: No significant facelift during production run
