BMW 5 Series wheel fitment — V E60/E61 Facelift
Overview
The fifth generation of the BMW 5 Series, known as the E60 (saloon) and E61 (Touring), was produced from July 5, 2003 to 2010. It introduced several new electronic features such as iDrive infotainment system, head-up display, active cruise control, adaptive headlights, night vision, lane departure warning, and voice control. The generation marked the first BMW 5 Series with a turbocharged petrol engine, a 6-speed automatic transmission, and regenerative braking. It was assembled in Germany, China, Mexico, India, Russia, Thailand, Indonesia, and Egypt.
BMW 5 Series wheel fitment
BMW 5 Series wheel fitment for the BMW 5 Series V (E60/E61) Facelift (2007–2010): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 72.6 mm |
| Bolt / thread | M12 x 1.5 (bolts) |
| Wheel-bolt torque | 120 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 7J–8.5J | ET6–ET26 |
| Rear (staggered) | 9J–10J | ET25–ET35 |
As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 196,854 BMW 5 Series on UK roads, placing it in the top 2% of car models by volume across our fitment database.
That makes BMW 5 Series wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive |
|---|---|---|---|---|
| 550i (N62B48) | 4.7L N62 V8 | petrol | 270 hp | RWD|AWD |
| 545i (N62B44) | 4.3L N62 V8 | petrol | 245 hp | RWD|AWD |
| 540i (N62B40) | 3.9L N62 V8 | petrol | 225 hp | RWD|AWD |
| 535i (N54B30) | 3.0L N54 turbo straight-6 | petrol | 225 hp | RWD|AWD |
| 530i (N53B30) | 3.0L N53 straight-6 | petrol | 200 hp | RWD|AWD |
| 530i (N52B30) | 3.0L N52 straight-6 | petrol | 190 hp | RWD|AWD |
| 528i (N52B30) | 3.0L N52 straight-6 | petrol | 172 hp | RWD|AWD |
| 530i (M54B30) | 3.0L M54 straight-6 | petrol | 170 hp | RWD|AWD |
| 530d (M57D30TÜ) | 3.0L M57 turbo straight-6 | diesel | 170 hp | RWD|AWD |
| 525i (N53B30) | 3.0L N53 straight-6 | petrol | 160 hp | RWD|AWD |
| 525i (N52B25) | 2.5L N52 straight-6 | petrol | 160 hp | RWD|AWD |
| 530d (M57D30) | 3.0L M57 turbo straight-6 | diesel | 160 hp | RWD|AWD |
| 525i (M54B25) | 2.5L M54 straight-6 | petrol | 141 hp | RWD|AWD |
| 523i (N53B25) | 2.5L N53 straight-6 | petrol | 140 hp | RWD|AWD |
| 523i (N52B25) | 2.5L N52 straight-6 | petrol | 130 hp | RWD|AWD |
| 520i (M54B22) | 2.2L M54 straight-6 | petrol | 125 hp | RWD|AWD |
| 520i (N43B20) | 2.0L N43 straight-4 | petrol | 125 hp | RWD|AWD |
| 520i (N46B20) | 2.0L N46 straight-4 | petrol | 115 hp | RWD|AWD |
Performance
| Variant | Power | 0–62 mph | Top speed |
|---|---|---|---|
| 535i (N54) | 306 hp | 5.1 s |
Dimensions
| Length | 4843 mm |
| Width | 1850 mm |
| Height | 1470 mm |
| Wheelbase | 2890 mm |
| Kerb weight | 1545 kg |
Body styles & production
| Body styles | Saloon, Touring |
| Produced | 2007–2010 |
Trim levels
Factory colours
History & notable variants
Development began in 1997 and concluded in 2002 under the leadership of Boyke Boyer and final design by Davide Arcangeli under Chris Bangle. The saloon was launched on July 5, 2003 in Europe and October 2003 in North America; Touring models were introduced late in 2004. In January 2010, the F10 generation succeeded it.
Reliability & owner notes
- Pros: Advanced electronic features; Turbocharged petrol engine option; All-wheel drive (xDrive) available
- Cons: Controversial design aesthetics; Initial safety ratings were lower than expected
- Common issues: Some models experienced issues with the iDrive system and SMG transmission reliability.
