BMW 6 Series wheel fitment — II E63/E64 Facelift
BMW 6 Series wheel fitment
Everything below is what the fit-check uses for BMW 6 Series wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the BMW 6 Series II (E63/E64) Facelift.
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 72.6 mm |
| Bolt / thread | M12 x 1.5 (bolts) |
| Wheel-bolt torque | 115 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8J–9J | ET5–ET23 |
| Rear (staggered) | 9J–10J | ET9–ET25 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 630i | 2,996 cc, N52B30 | petrol | 190 kW (258 PS) | 2004 to 2007 |
| 630i | 2,996 cc, N53B30 | petrol | 200 kW (272 PS) | 2007 to 2010 |
| 645Ci | 4,398 cc, N62B44 | 245 kW (333 PS) | 2003 to 2005 | |
| 650i | 4,799 cc, N62B48TÜ | petrol | 270 kW (367 PS) | 2005 to 2010 |
| M6 | 4,999 cc, S85B50 | 373 kW (507 PS) | 2005 to 2010 | |
| 635d | 2,993 cc, M57D30TÜ | diesel | 210 kW (286 PS) | 2007 to 2010 |
| B6 | 4,398 cc | 368 kW (500 PS) | 2005 to 2007 | |
| B6 S | 4,398 cc | 390 kW (530 PS) | 2007 to 2010 |
Source: BMW E63, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 630i | 190 kW (258 PS) | 6.5 s | |
| 630i | 200 kW (272 PS) | 6.2 s | |
| 645Ci | 245 kW (333 PS) | 5.6 s | |
| 650i | 270 kW (367 PS) | 5.1 s | |
| M6 | 373 kW (507 PS) | 4.6 s | |
| 635d | 210 kW (286 PS) | 6.3 s |
Source: BMW E63, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 19,390 BMW 6 Series on UK roads, placing it in the top 11% of car models by volume across our fitment database.
With that many on the road, BMW 6 Series wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 4,820 mm |
| Width | 1,855 mm |
| Height | 1,374 mm |
| Wheelbase | 2,780 mm |
| Kerb weight | 1,575 to 1,925 kg |
Source: BMW E63, de.wikipedia.org.
Body styles & production
| Body styles | 2-door coupé (E63), 2-door convertible (E64) |
| Produced | 2007–2010 |
