BMW 7 Series wheel fitment — VII G70
BMW 7 Series wheel fitment
BMW 7 Series wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the BMW 7 Series VII (G70) (2022–2026).
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8.5J–9.5J | ET15–ET30 |
| Rear (staggered) | 9J–10.5J | ET19–ET45 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 735i | BMW B58, 2,998 cc | petrol | 210 kW (286 PS) | 2022 to 2026 |
| 740i | BMW B58, 2,998 cc | petrol | 280 kW (380 PS) | 2022 to 2026 |
| 740 xDrive | BMW B58, 2,998 cc | 294 kW (400 PS) | xDrive, 2026 to present | |
| 760i xDrive | BMW S68, 4,395 cc | petrol | 400 kW (544 PS) | xDrive, 2022 to 2026 |
| 740d xDrive | BMW B57, 2,993 cc | diesel | 220 kW (299 PS) | xDrive, 2023 |
| 740d xDrive | BMW B57, 2,993 cc | diesel | 230 kW (313 PS) | xDrive, 2026 to present |
| 750e | BMW B58, 2,998 cc | phev | 360 kW (489 PS) | 2026 to present |
| 750e xDrive | BMW B58, 2,998 cc | phev | 360 kW (489 PS) | xDrive, 2023 |
| 750e xDrive | BMW B58, 2,998 cc | phev | 360 kW (489 PS) | xDrive, 2026 |
| M760e xDrive | BMW B58, 2,998 cc | 420 kW (571 PS) | xDrive, 2023 | |
| M760e xDrive | BMW B58, 2,998 cc | 450 kW (612 PS) | xDrive, 2026 | |
| i7 eDrive50 | Hinterachse: HA0004N0 | 335 kW (455 PS) | 2023 to 2026 | |
| i7 50 xDrive | 335 kW (455 PS) | xDrive, 2026 to present | ||
| i7 xDrive60 | Vorderachse: HA0002N0, Hinterachse: HA0003N0 | 400 kW (544 PS) | xDrive, 2022 to 2026 | |
| i7 60 xDrive | 400 kW (544 PS) | xDrive, 2026 to present | ||
| i7 M70 xDrive | Vorderachse: HA0002N0, Hinterachse: HA0004N0 | 485 kW (660 PS) | xDrive, 2023 to 2026 | |
| i7 M70 xDrive | 500 kW (680 PS) | xDrive, 2026 to present |
Source: BMW G70, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 18,023 BMW 7 Series on UK roads, placing it in the top 11% of car models by volume across our fitment database.
With that many on the road, BMW 7 Series wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 5,391 to 5,395 mm |
| Width | 1,950 mm |
| Height | 1,544 to 1,550 mm |
| Wheelbase | 3,215 mm |
| Kerb weight | 2,215 to 2,590 kg |
Source: BMW G70, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | 4-door sedan |
| Produced | 2022–2026 |
