BMW i5 wheel fitment — G60/G61/G68
Overview
The BMW 5 Series (G60) represents the eighth generation of this executive car series manufactured by BMW since July 2023. It is built on an updated version of the rear-wheel drive Cluster Architecture (CLAR) platform, shared with the larger G70 7 Series. The lineup includes the G60 saloon, G61 estate (Touring), and the long-wheelbase G68 model exclusive to China. This generation introduces a battery electric powertrain variant called 'i5', offering three models: eDrive40, xDrive40, and M60 xDrive.
BMW i5 wheel fitment
Start with the hub. The BMW i5 G60/G61/G68 spec table gives the bolt pattern and bore; the second table is the aftermarket window for BMW i5 wheel fitment.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8.5J–9J | ET22–ET36 |
| Rear (staggered) | 9.5J–10J | ET40–ET50 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 8,372 BMW i5 on UK roads, placing it in the top 15% of car models by volume across our fitment database.
That makes BMW i5 wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 520i | BMW B48B20P, 1,998 cc | petrol | 153 kW (208 PS) | RWD, 2023 to present |
| 530i | 1,998 cc | petrol | 190 kW (258 PS) | RWD, 2023 to present |
| 530i xDrive | 1,998 cc | petrol | 190 kW (258 PS) | xDrive, 2023 to present |
| 540i xDrive | BMW B58TÜ2, 2,998 cc | petrol | 280 kW (381 PS) | xDrive, 2024 to present |
| 530e | 1,998 cc | phev | 220 kW (299 PS) | RWD, 2023 to present |
| 530e xDrive | 1,998 cc | phev | 220 kW (299 PS) | xDrive, 2024 to present |
| 550e xDrive | BMW B58B30S, 2,998 cc | phev | 360 kW (489 PS) | xDrive, 2023 to present |
| M5 | 4,395 cc | 535 kW (727 PS) | AWD, 2024 to 2026 | |
| M5 | 4,395 cc | 535 kW (727 PS) | AWD, 2026 to present | |
| 520d | BMW B47D20B, 1,995 cc | diesel | 145 kW (197 PS) | RWD, 2023 to present |
| 520d xDrive | BMW B47D20B, 1,995 cc | diesel | 145 kW (197 PS) | xDrive, 2023 to present |
| 540d xDrive | B57D30O2, 2,993 cc | diesel | 223 kW (303 PS) | xDrive, 2024 to present |
Source: BMW G60, de.wikipedia.org.
Dimensions
| Length | 5,060 to 5,096 mm |
| Width | 1,900 to 1,970 mm |
| Height | 1,505 to 1,516 mm |
| Wheelbase | 2,995 to 3,006 mm |
| Kerb weight | 1,680 to 2,555 kg |
Source: BMW G60, de.wikipedia.org.
Body styles & production
| Body styles | 4-door saloon (G60), 5-door estate (G61) |
| Produced | 2024–2024 |
Trim levels
Factory colours
History & notable variants
Development of the BMW 5 Series (G60) began with testing in February 2022, including rigorous winter tests in Arjeplog, Sweden. The car was officially revealed on May 24, 2023, and production commenced at Dingolfing Plant in July 2023. Sales started in October of the same year. The G61 Touring variant debuted in February 2024.
Reliability & owner notes
- Pros: Advanced iDrive 8.5 infotainment system, improved aerodynamics, enhanced electric motor efficiency
- Cons: Limited availability of diesel models in certain markets, higher cost for premium features
