BMW M2 wheel fitment — F87 Facelift
BMW M2 wheel fitment
Everything below is what the fit-check uses for BMW M2 wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the BMW M2 F87 Facelift.
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 72.6 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8.5J–9J | ET14–ET27 |
| Rear (staggered) | 9J–9.5J | ET19–ET35 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 3.0 L N55B30T0 turbo I6 | ||||
| 3.0 L S55B30T0 twin-turbo I6 (Competition & CS) |
Source: BMW M2, en.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 24,390 BMW M2 on UK roads, placing it in the top 9% of car models by volume across our fitment database.
With that many on the road, BMW M2 wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 4,468 mm |
| Width | 1,854 mm |
| Height | 1,410 mm |
| Wheelbase | 2,693 mm |
| Kerb weight | 1,570 to 1,595 kg |
Source: BMW M2, en.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Produced | 2017–2021 |
