BMW M2 wheel fitment — F87
BMW M2 wheel fitment
BMW M2 wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the BMW M2 F87 (2015–2017).
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 72.6 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8.5J–9J | ET14–ET27 |
| Rear (staggered) | 9J–9.5J | ET19–ET35 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 3.0 L N55B30T0 turbo I6 | ||||
| 3.0 L S55B30T0 twin-turbo I6 (Competition & CS) |
Source: BMW M2, en.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 24,390 BMW M2 on UK roads, placing it in the top 9% of car models by volume across our fitment database.
That makes BMW M2 wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 4,468 mm |
| Width | 1,854 mm |
| Height | 1,410 mm |
| Wheelbase | 2,693 mm |
| Kerb weight | 1,495 kg |
Source: BMW M2, en.wikipedia.org.
Body styles & production
| Produced | 2015–2017 |
