BMW M3 wheel fitment — E90/E92/E93
BMW M3 wheel fitment
BMW M3 wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the BMW M3 E90/E92/E93 (2007–2013).
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 72.6 mm |
| Bolt / thread | M12 x 1.5 (bolts) |
| Wheel-bolt torque | 115 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8J–9J | ET10–ET25 |
| Rear (staggered) | 9J–10J | ET23–ET40 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Overview
The BMW M3 E90/E92/E93 is a high-performance version of the BMW 3 Series produced by BMW's in-house motorsport division, BMW M GmbH. This generation covers the period from 2007 to 2013 and was available as saloon (E90), coupé (E92), and convertible (E93) body styles. It succeeded the E46 generation and marked a significant shift with its use of a straight-six engine, though it reverted to rear-wheel drive from the previous all-wheel-drive setup. The M3 was positioned as a premium sports sedan offering exceptional performance and handling.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 316i | 1,599 cc, N45B16 | petrol | 90 kW (122 PS) | 2007 to 2011 |
| 318i | 1,995 cc, N46B20 | petrol | 95 kW (129 PS) | 2005 to 2007 |
| 318i | 1,995 cc, N43B20 (N46NB20) | petrol | 105 kW (143 PS) | 2007 to 2012 |
| 320i | 1,995 cc, N46B20 | petrol | 110 kW (150 PS) | 2005 to 2007 |
| 320i | 1,995 cc, N43B20 (N46NB20) | petrol | 125 kW (170 PS) | 2007 to 2012 |
| 320si | 1,997 cc, N45B20S | petrol | 127 kW (173 PS) | 2006 to 2007 |
| 323i | 2,497 cc, N52B25 | petrol | 130 kW (177 PS) | 2005 to 2007 |
| 323i | 2,497 cc, N52B25 | petrol | 149 kW (203 PS) | 2007 to 2010 |
| 325i | 2,497 cc, N52B25 | petrol | 160 kW (218 PS) | 2005 to 2007 |
| 325xi | 2,497 cc, N52B25 | petrol | 160 kW (218 PS) | 2005 to 2007 |
| 325i | 2,996 cc, N53B30 | petrol | 160 kW (218 PS) | 2007 to 2012 |
| 325i xDrive | 2,996 cc, N53B30 | petrol | 160 kW (218 PS) | xDrive, 2007 to 2012 |
| 328i | 2,996 cc, N52B30 | petrol | 172 kW (233 PS) | 2007 to 2011 |
| 330i | 2,996 cc, N52B30 | petrol | 190 kW (258 PS) | 2005 to 2007 |
| 330xi | 2,996 cc, N52B30 | petrol | 190 kW (258 PS) | 2005 to 2007 |
| 330i | 2,996 cc, N53B30 | petrol | 200 kW (272 PS) | 2007 to 2012 |
| 330i xDrive | 2,996 cc, N53B30 | petrol | 200 kW (272 PS) | xDrive, 2007 to 2012 |
| 335i | 2,979 cc, N54B30 | petrol | 225 kW (306 PS) | 2006 to 2010 |
| 335i xDrive | 2,979 cc, N54B30 | petrol | 225 kW (306 PS) | xDrive, 2006 to 2010 |
| 335i | 2,979 cc, N55B30 | petrol | 225 kW (306 PS) | 2010 to 2012 |
| 335i xDrive | 2,979 cc, N55B30 | petrol | 225 kW (306 PS) | xDrive, 2010 to 2012 |
| M3 | 3,999 cc, S65B40 | petrol | 309 kW (420 PS) | 2008 to 2013 |
| 316d | 1,995 cc, N47D20 | diesel | 85 kW (116 PS) | 2009 to 2011 |
| 318d | 1,995 cc, M47D20TÜ2 | diesel | 90 kW (122 PS) | 2005 to 2007 |
| 318d | 1,995 cc, N47D20 | diesel | 105 kW (143 PS) | 2007 to 2009 |
| 318d | 1,995 cc, N47D20 | diesel | 105 kW (143 PS) | 2009 to 2010 |
| 318d | 1,995 cc, N47D20 | diesel | 105 kW (143 PS) | 2010 to 2012 |
| 320d Edition Fleet | 1,995 cc, M47D20TÜ2 | diesel | 110 kW (150 PS) | 2005 to 2007 |
| 320d | 1,995 cc, M47D20TÜ2 | diesel | 120 kW (163 PS) | 2005 to 2007 |
| 320d Edition Fleet | 1,995 cc, N47D20 | diesel | 120 kW (163 PS) | 2007 to 2010 |
| 320d Edition Fleet | 1,995 cc, N47D20 | diesel | 120 kW (163 PS) | 2010 to 2012 |
| 320d "Efficient-Dynamics" Edition | 1,995 cc, N47D20 | diesel | 120 kW (163 PS) | 2010 to 2011 |
| 320d | 1,995 cc, N47D20 | diesel | 130 kW (177 PS) | 2007 to 2010 |
| 320d xDrive | 1,995 cc, N47D20 | diesel | 130 kW (177 PS) | xDrive, 2008 to 2010 |
| 320d | 1,995 cc, N47D20 | diesel | 135 kW (184 PS) | 2010 |
| 320d xDrive | 1,995 cc, N47D20 | diesel | 135 kW (184 PS) | xDrive, 2010 to 2012 |
| 325d | 2,993 cc, M57D30TÜ2 | diesel | 145 kW (197 PS) | 2006 to 2010 |
| 325d | 2,993 cc, N57D30 | diesel | 150 kW (204 PS) | 2010 to 2013 |
| 330d | 2,993 cc, M57D30TÜ2 | diesel | 170 kW (231 PS) | 2005 to 2008 |
| 330xd | 2,993 cc, M57D30TÜ2 | diesel | 170 kW (231 PS) | 2005 to 2008 |
Source: BMW E90, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 316i | 90 kW (122 PS) | 10.8 s | |
| 318i | 95 kW (129 PS) | 10 s | |
| 318i | 105 kW (143 PS) | 9.1 s | |
| 320i | 110 kW (150 PS) | 8.8 s | |
| 320i | 125 kW (170 PS) | 8.2 s | |
| 320si | 127 kW (173 PS) | 8.1 s | |
| 323i | 130 kW (177 PS) | 8 s | |
| 323i | 149 kW (203 PS) | 7.4 s | |
| 325i | 160 kW (218 PS) | 7 s | |
| 325xi | 160 kW (218 PS) | 7.5 s | |
| 325i | 160 kW (218 PS) | 6.7 s | |
| 325i xDrive | 160 kW (218 PS) | 7.3 s | |
| 328i | 172 kW (233 PS) | 6.7 s | |
| 330i | 190 kW (258 PS) | 6.3 s | |
| 330xi | 190 kW (258 PS) | 6.4 s | |
| 330i | 200 kW (272 PS) | 6.1 s | |
| 330i xDrive | 200 kW (272 PS) | 6.2 s | |
| 335i | 225 kW (306 PS) | 5.6 s | |
| 335i xDrive | 225 kW (306 PS) | 5.5 s | |
| 335i | 225 kW (306 PS) | 5.6 s | |
| 335i xDrive | 225 kW (306 PS) | 5.4 s | |
| M3 | 309 kW (420 PS) | 4.9 s | |
| 316d | 85 kW (116 PS) | 10.9 s | |
| 318d | 90 kW (122 PS) | 10.6 s | |
| 318d | 105 kW (143 PS) | 9.3 s | |
| 318d | 105 kW (143 PS) | 9.3 s | |
| 318d | 105 kW (143 PS) | 9.1 s | |
| 320d Edition Fleet | 110 kW (150 PS) | 8.7 s | |
| 320d | 120 kW (163 PS) | 8.3 s | |
| 320d Edition Fleet | 120 kW (163 PS) | 8.2 s | |
| 320d Edition Fleet | 120 kW (163 PS) | 8 s | |
| 320d "Efficient-Dynamics" Edition | 120 kW (163 PS) | 8 s | |
| 320d | 130 kW (177 PS) | 7.9 s | |
| 320d xDrive | 130 kW (177 PS) | 8.2 s | |
| 320d | 135 kW (184 PS) | 7.5 s | |
| 320d xDrive | 135 kW (184 PS) | 7.9 s | |
| 325d | 145 kW (197 PS) | 7.4 s | |
| 325d | 150 kW (204 PS) | 7 s | |
| 330d | 170 kW (231 PS) | 6.7 s | |
| 330xd | 170 kW (231 PS) | 6.6 s |
Source: BMW E90, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 27,392 BMW M3 on UK roads, placing it in the top 9% of car models by volume across our fitment database.
A parc that size is why BMW M3 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
History & notable variants
The BMW M3 E90/E92/E93 saw notable development during its production period, including a mid-cycle facelift (LCI) in 2010 that introduced cosmetic changes and minor mechanical updates. Special/performance variants included the Competition Package which enhanced performance further. The model received positive reception for its blend of luxury and high-performance capabilities.
Dimensions
| Length | 4,520 to 4,580 mm |
| Width | 1,782 to 1,817 mm |
| Height | 1,395 to 1,421 mm |
| Wheelbase | 2,760 mm |
| Kerb weight | 1,425 to 1,825 kg |
Source: BMW E90, de.wikipedia.org.
Body styles & production
| Body styles | 4-door saloon (E90), 2-door coupé (E92), 2-door convertible (E93) |
| Produced | 2007–2013 |
Trim levels
Factory colours
Reliability & owner notes
- Pros: High-performance capabilities, luxurious interior, advanced technology features
- Cons: Expensive maintenance costs, high fuel consumption
- Common issues: None specified in reference
