BMW M5 wheel fitment — V F10
BMW M5 wheel fitment
BMW M5 wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the BMW M5 V (F10) (2011–2013).
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 72.6 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | none |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 9J–10J | ET12–ET25 |
| Rear (staggered) | 10J–11J | ET24–ET41 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Overview
The BMW M5 is a high-performance version of the BMW 5 Series automobile developed by BMW's motorsport division, BMW M GmbH. It has been continuously produced since 1984 in saloon body style and occasionally as an estate model in some markets. The first generation (E28) was hand-built on the E28 535i chassis with a modified engine from the M1 sports car, making it the fastest production saloon at its launch. Production has been periodic, with gaps between generations.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 4.4 L S63 twin-turbo V8 |
Source: BMW M5, en.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 6,002 BMW M5 on UK roads, placing it in the top 17% of car models by volume across our fitment database.
A parc that size is why BMW M5 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
History & notable variants
The E28 M5 was produced from October 1984 to June 1988 and made its debut at the Amsterdam Motor Show in February 1985. It featured a modified engine from the BMW M1 sports car and was available in Europe, Great Britain, the United States, Canada, and South Africa. The E34 generation followed from September 1988 to August 1995 with notable upgrades including an upgraded engine and special editions like the Cecotto and Winkelhock models.
Dimensions
| Length | 4,910 mm |
| Width | 1,891 mm |
| Height | 1,451 mm |
| Wheelbase | 2,970 mm |
| Kerb weight | 1,990 kg |
Source: BMW M5, en.wikipedia.org.
Body styles & production
| Body styles | 4-door saloon |
| Produced | 2011–2013 |
Trim levels
Factory colours
Reliability & owner notes
- Pros: High-performance capabilities, luxury features, hand-built quality
- Cons: Limited production numbers, high price point
- Common issues: None explicitly mentioned
