What size wheels fit a BMW M5 VI (F90)?

Roughly 9.5J–10.5J (ET16–ET35); staggered setups run 10J–11J rear.

How many BMW M5 are there on UK roads?

Approximately 6,002 BMW M5 are licensed in the UK, according to DfT VEH0124 vehicle-parc data (2025).

BMW M5 wheel fitment — VI F90

By Torque, AIWheelTech vehicle & fitment specialist · 2017–2020

Quick answer on BMW M5 wheel fitment: The BMW M5 VI (F90) (2017–2020) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14 x 1.25 bolts torqued to ~140 Nm. It accepts ~9.5J–10.5J wheels at ET16–ET35 front; staggered setups run 10J–11J rear (ET14–ET40).

BMW M5 wheel fitment

BMW M5 wheel fitment for the BMW M5 VI (F90) (2017–2020): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)	5x112
Centre bore	66.6 mm
Bolt / thread	M14 x 1.25 (bolts)
Wheel-bolt torque	140 Nm
Seat type	tapered
Factory setup	staggered
TPMS	direct
Run-flat	Yes

Aftermarket wheel sizes — read per position:

Position	Width	Offset
Front	9.5J–10.5J	ET16–ET35
Rear (staggered)	10J–11J	ET14–ET40

Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.

Browse wheels that fit a BMW M5 →Get them fitted (UK)

UK popularity & demand

~6,002 BMW M5 licensed on UK roads — top 17% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 6,002 BMW M5 on UK roads, placing it in the top 17% of car models by volume across our fitment database.

A parc that size is why BMW M5 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Overview

The BMW M5 VI (F90) is a high-performance version of the BMW 5 Series produced from 2017 to 2020. Built by BMW's motorsport division in Munich, Germany, it features an all-wheel-drive layout and represents a significant shift from previous generations with its powerful V8 engine and advanced technology. The M5 VI is positioned as a top-tier executive car, offering both performance and luxury.

Dimensions

Length	4,965 mm
Width	1,903 mm
Height	1,473 mm
Wheelbase	2,982 mm
Kerb weight	1,835 to 1,950 kg

Source: BMW M5, en.wikipedia.org; EU type-approval data (EEA).

Body styles & production

Body styles	4-door saloon
Produced	2017–2020

Engines & drivetrain

Variant	Engine	Fuel	Power	Drive, years
4.4 L S63 twin-turbo V8

Source: BMW M5, en.wikipedia.org.

Trim levels

M5 Competition

Factory colours

Alpinweiss IAlpinweiss IIIArktisblau MetallicBlackBlacksapphire MetallicBlauewater MetallicBronzit MetallicBurgundy Red MetallicCalypsorot MetallicCarbonschwarz MetallicCinnabar RedCosmos Blue MetallicDelphin MetallicDiamond Black MetallicHenna RedImolarot II SolidKalaharibeige MetallicLapis BlueLemansblau MetallicPolaris Metallic

History & notable variants

The F90 generation of the BMW M5 was introduced in 2017 at the Geneva Motor Show. It marked a significant departure from earlier models with its all-wheel-drive setup and advanced technology features. In 2018, it received minor updates to enhance its performance and efficiency. The car won several awards for its blend of luxury and high-performance capabilities.

Reliability & owner notes

Pros: Powerful V8 engine; advanced all-wheel-drive system; luxurious interior; high-tech features
Cons: High price point; complex technology may be daunting for some users
