BMW X3 M wheel fitment — F97
BMW X3 M wheel fitment
BMW X3 M wheel fitment for the BMW X3 M F97 (2017–2024): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8.5J–9.5J | ET7–ET30 |
| Rear (staggered) | 10J–11J | ET24–ET44 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 123,411 BMW X3 M range on UK roads, placing it in the top 3% of car models by volume across our fitment database.
A parc that size is why BMW X3 M wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Overview
The BMW X3 M F97 is part of the third generation G01 model line produced from 2017 to 2024. It was manufactured at both BMW's Rosslyn plant in South Africa and Spartanburg plant in the USA. The car is based on the Compact luxury crossover SUV platform, offering a high-performance variant with enhanced powertrain and styling compared to its standard X3 siblings.
Dimensions
| Length | 4,708 to 4,734 mm |
| Width | 1,891 to 1,897 mm |
| Height | 1,667 to 1,676 mm |
| Wheelbase | 2,864 mm |
| Kerb weight | 1,860 to 2,085 kg |
Source: BMW G01, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | Kombi |
| Produced | 2017–2024 |
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| sDrive20i | 1,998 cc, Motorkenndaten | petrol | 135 kW (184 PS) | RWD, 2017 to 2024 |
| xDrive20i | 1,998 cc, Motorkenndaten | petrol | 135 kW (184 PS) | xDrive, 2017 to 2021 |
| xDrive20i | 1,998 cc, Motorkenndaten | petrol | 135 kW (184 PS) | xDrive, 2021 to 2024 |
| xDrive28i | 1,998 cc, Motorkenndaten | petrol | 165 kW (224 PS) | xDrive |
| xDrive30i | 1,998 cc, Motorkenndaten | petrol | 180 kW (245 PS) | xDrive, 2021 to 2024 |
| xDrive30i | 1,998 cc, Motorkenndaten | petrol | 185 kW (252 PS) | xDrive, 2017 to 2021 |
| M40i | 2,998 cc, Motorkenndaten | petrol | 260 kW (354 PS) | AWD, 2018 to 2019 |
| M40i | 2,998 cc, Motorkenndaten | petrol | 265 kW (360 PS) | AWD, 2017 to 2018 |
| M40i | 2,998 cc, Motorkenndaten | petrol | 265 kW (360 PS) | AWD, 2019 to 2021 |
| M40i | 2,998 cc, Motorkenndaten | petrol | 265 kW (360 PS) | AWD, 2021 to 2024 |
| M [F97] | 2,993 cc, Motorkenndaten | petrol | 353 kW (480 PS) | AWD, 2019 to 2021 |
| M Competition [F97] | 2,993 cc, Motorkenndaten | petrol | 375 kW (510 PS) | AWD, 2019 to 2021 |
| M Competition [F97] | 2,993 cc, Motorkenndaten | petrol | 375 kW (510 PS) | AWD, 2021 to 2024 |
| xDrive30e | 1,998 cc, Motorkenndaten | hybrid | 215 kW (292 PS) | xDrive, 2019 to 2024 |
| sDrive18d | 1,995 cc, Motorkenndaten | diesel | 110 kW (150 PS) | RWD |
| xDrive20d | 1,995 cc, Motorkenndaten | diesel | 140 kW (190 PS) | xDrive, 2017 to 2021 |
| xDrive20d | 1,995 cc, Motorkenndaten | diesel | 140 kW (190 PS) | xDrive, 2021 to 2024 |
| xDrive25d | 1,995 cc, Motorkenndaten | diesel | 170 kW (231 PS) | xDrive, 2018 to 2019 |
| xDrive30d | 2,993 cc, Motorkenndaten | diesel | 195 kW (265 PS) | xDrive, 2017 to 2019 |
| xDrive30d | 2,993 cc, Motorkenndaten | diesel | 210 kW (286 PS) | xDrive, 2020 to 2021 |
| xDrive30d | 2,993 cc, Motorkenndaten | diesel | 210 kW (286 PS) | xDrive, 2021 to 2024 |
| M40d | 2,993 cc, Motorkenndaten | diesel | 240 kW (326 PS) | AWD, 2018 to 2019 |
| M40d | 2,993 cc, Motorkenndaten | diesel | 250 kW (340 PS) | AWD, 2020 to 2021 |
| M40d | 2,993 cc, Motorkenndaten | diesel | 250 kW (340 PS) | AWD, 2021 to 2024 |
| iX3 | HA0001N0 | electric | 210 kW (286 PS) | RWD, 2021 to 2025 |
Source: BMW G01, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| sDrive20i | 135 kW (184 PS) | 8.3 s | |
| xDrive20i | 135 kW (184 PS) | 8.3 s | |
| xDrive20i | 135 kW (184 PS) | 8.4 s | |
| xDrive28i | 165 kW (224 PS) | 7.6 s | |
| xDrive30i | 180 kW (245 PS) | 6.6 s | |
| xDrive30i | 185 kW (252 PS) | 6.3 s | |
| M40i | 260 kW (354 PS) | 4.8 s | |
| M40i | 265 kW (360 PS) | 4.8 s | |
| M40i | 265 kW (360 PS) | 4.8 s | |
| M40i | 265 kW (360 PS) | 4.9 s | |
| M [F97] | 353 kW (480 PS) | 4.2 s | |
| M Competition [F97] | 375 kW (510 PS) | 4.1 s | |
| M Competition [F97] | 375 kW (510 PS) | 3.8 s | |
| xDrive30e | 215 kW (292 PS) | 6.1 s | |
| sDrive18d | 110 kW (150 PS) | 9.5 to 9.7 s | |
| xDrive20d | 140 kW (190 PS) | 8 s | |
| xDrive20d | 140 kW (190 PS) | 7.9 s | |
| xDrive25d | 170 kW (231 PS) | 6.8 s | |
| xDrive30d | 195 kW (265 PS) | 5.8 s | |
| xDrive30d | 210 kW (286 PS) | 5.7 s | |
| xDrive30d | 210 kW (286 PS) | 5.7 s | |
| M40d | 240 kW (326 PS) | 4.9 s | |
| M40d | 250 kW (340 PS) | 4.9 s | |
| M40d | 250 kW (340 PS) | 4.9 s | |
| iX3 | 210 kW (286 PS) | 6.8 s |
Source: BMW G01, de.wikipedia.org.
Trim levels
Factory colours
History & notable variants
In 2019, BMW introduced the first M version of the X3 (F97) featuring a powerful 3.0 L S58 engine. This model marked an expansion into the performance SUV segment, competing with high-performance variants from other luxury brands like Mercedes-AMG and Audi RS.
Reliability & owner notes
- Pros: High-performance engine; advanced safety features; luxury interior
- Cons: Limited production; high price point
