BMW X3 wheel fitment — IV G45
Overview
The BMW X3 IV (G45/G48) is a compact luxury crossover SUV manufactured by BMW from 2024 onwards, replacing the third-generation G01 model. Built on the CLAR platform, it offers mild hybrid and plug-in hybrid powertrains. The fourth generation features a lowered roofline for a sportier silhouette and advanced interior technology like the full digital Curved Display with iDrive 9 infotainment system. Production occurs in multiple locations including South Carolina (U.S.), Rosslyn (South Africa), Dadong (China), Jakarta (Indonesia), Kulim (Malaysia), and Chu Lai (Vietnam).
BMW X3 wheel fitment
Start with the hub. The BMW X3 IV (G45) spec table gives the bolt pattern and bore; the second table is the aftermarket window for BMW X3 wheel fitment.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8J–9.5J | ET5–ET30 |
| Rear (staggered) | 9J–11J | ET17–ET42 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 123,411 BMW X3 on UK roads, placing it in the top 3% of car models by volume across our fitment database.
A parc that size is why BMW X3 wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 20 xDrive | 1,998 cc, B48 | hybrid | 187 hp | xDrive |
| 30 xDrive | 1,998 cc, B48 | hybrid | 251 hp | xDrive |
| M50 xDrive* | 2,998 cc, B58 | hybrid | 376 hp | xDrive |
| 30e xDrive | 1,998 cc, B48 | phev | 187 hp | xDrive |
| 20d xDrive | 1,995 cc, B47 | hybrid | 194 hp | xDrive |
| 40d xDrive | 2,993 cc, B57 | hybrid | 282 hp | xDrive |
Source: BMW X3 (G45), en.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 20 xDrive | 187 hp | 7.8 s | 215 km/h (134 mph) |
| 30 xDrive | 251 hp | 6.3 s | 210 km/h (130 mph) |
| M50 xDrive* | 376 hp | 4.6 s | 250 km/h (155 mph) |
| 30e xDrive | 187 hp | 6.2 s | 215 km/h (134 mph) |
| 20d xDrive | 194 hp | 7.7 s | 215 km/h (134 mph) |
| 40d xDrive | 282 hp | 5.4 s | 245 km/h (152 mph) |
Source: BMW X3 (G45), en.wikipedia.org.
Dimensions
| Length | 4,755 to 4,865 mm |
| Width | 1,920 mm |
| Height | 1,660 mm |
| Wheelbase | 2,865 to 2,975 mm |
Source: BMW X3 (G45), en.wikipedia.org.
Body styles & production
| Body styles | 5-door SUV |
| Produced | 2024–2026 |
| Units produced | 180,000 |
Trim levels
Factory colours
History & notable variants
Unveiled on June 19, 2024, the G45 X3 was launched in late 2024 for the 2025 model year. Notable features include a larger kidney grille with optional Iconic Glow contour lighting and adaptive LED headlights. The interior introduces BMW's Curved Display and recycled polyester options. South Africa is the sole producer of plug-in hybrid models, while China received an LWB variant (G48) exclusive to its market.
Reliability & owner notes
- Pros: Advanced technology features, improved aerodynamics, increased boot space with powered tailgate, available long-wheelbase variant for Chinese market
- Cons: Limited availability of electric models on the same platform as previous generation, reduced boot capacity in 30e model due to battery placement
