BMW X5 wheel fitment — II E70 LCI
BMW X5 wheel fitment
BMW X5 wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the BMW X5 II (E70) LCI (2010–2013).
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 74.1 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 8.5J–10J | ET12–ET35 |
| Rear (staggered) | 10J–11.5J | ET27–ET50 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
Overview
The BMW X5 II (E70) is the second generation of the mid-size luxury crossover SUV produced by BMW from July 2006 to June 2013, replacing the E53 model. It was manufactured at BMW's plants in Greer, South Carolina and Toluca, Mexico. The E70 features a longer wheelbase (2933 mm) compared to its predecessor, offering more interior space and improved ride quality with double wishbone suspension at the front. Notable technological advancements include iDrive system integration, LED taillamps, and advanced safety features such as active steering and Dynamic Drive.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| 3.0si/xDrive30i | 2,996 cc | 200 kW (272 PS) | xDrive, 2006 to 2010 | |
| xDrive35i | 2,979 cc | 225 kW (306 PS) | xDrive, 2010 to 2013 | |
| 4.8i/xDrive48i | 4,799 cc | 261 kW (355 PS) | xDrive, 2006 to 2010 | |
| xDrive50i | 4,395 cc | 300 kW (408 PS) | xDrive, 2010 to 2013 | |
| X5 M | 4,395 cc | 408 kW (555 PS) | 2009 to 2013 | |
| 3.0d/xDrive30d | 2,993 cc | 173 kW (235 PS) | xDrive, 2007 to 2010 | |
| xDrive30d | 2,993 cc | 180 kW (245 PS) | xDrive, 2010 to 2013 | |
| 3.0sd/xDrive35d | 2,993 cc | 210 kW (286 PS) | xDrive, 2007 to 2010 | |
| xDrive40d | 2,993 cc | 225 kW (306 PS) | xDrive, 2010 to 2013 | |
| M50d | 2,993 cc | 280 kW (381 PS) | 2012 to 2013 |
Source: BMW E70, de.wikipedia.org.
Performance
| Variant | Power | 0 to 62 mph (0 to 100 km/h) | Top speed |
|---|---|---|---|
| 3.0si/xDrive30i | 200 kW (272 PS) | 8.1 s | 210 km/h (130 mph) |
| xDrive35i | 225 kW (306 PS) | 6.8 s | 240 km/h (149 mph) |
| 4.8i/xDrive48i | 261 kW (355 PS) | 6.5 s | 240 km/h (149 mph) |
| xDrive50i | 300 kW (408 PS) | 5.5 s | 250 km/h (155 mph) |
| X5 M | 408 kW (555 PS) | 4.7 s | 250 km/h (155 mph) |
| 3.0d/xDrive30d | 173 kW (235 PS) | 8.1 s | 210 km/h (130 mph) |
| xDrive30d | 180 kW (245 PS) | 7.6 s | 222 km/h (138 mph) |
| 3.0sd/xDrive35d | 210 kW (286 PS) | 7 s | 235 km/h (146 mph) |
| xDrive40d | 225 kW (306 PS) | 6.6 s | 236 km/h (147 mph) |
| M50d | 280 kW (381 PS) | 5.4 s | 250 km/h (155 mph) |
Source: BMW E70, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 105,319 BMW X5 on UK roads, placing it in the top 4% of car models by volume across our fitment database.
With that many on the road, BMW X5 wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
History & notable variants
The E70 underwent a Life Cycle Impulse (LCI) update in 2010, introducing revised styling and new engine options with turbocharging and direct injection. The X5 M high-performance variant was introduced for the 2010 model year, marking BMW's first xDrive all-wheel-drive vehicle from M GmbH.
Dimensions
| Length | 4,854 mm |
| Width | 1,933 mm |
| Height | 1,739 mm |
| Wheelbase | 2,933 mm |
| Kerb weight | 2,125 to 2,380 kg |
Source: BMW E70, de.wikipedia.org.
Body styles & production
| Body styles | 5-door SUV |
| Produced | 2010–2013 |
Trim levels
Factory colours
Reliability & owner notes
- Pros: Advanced technology features; Improved interior space and comfort
- Cons: Manual transmission not available
