BMW XM wheel fitment — G09
Overview
The BMW XM G09 is a full-size luxury crossover SUV manufactured by BMW M since December 2022 at the Plant Spartanburg in Greer, South Carolina. It features a plug-in hybrid drivetrain with options for both petrol engines and electric motors, making it the second car developed entirely by BMW M after the BMW M1. The XM comes in various trims including XM 50e, XM, XM Label Red, each offering different levels of power and performance.
History & notable variants
The development of the BMW XM began with its unveiling as a concept vehicle at Art Basel Miami Beach on November 29, 2021. Production commenced in December 2022, with deliveries starting in 2023. The model includes special editions like the XM Label Red, limited to 500 units globally.
BMW XM wheel fitment
Everything below is what the fit-check uses for BMW XM wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the BMW XM G09.
| Bolt pattern (PCD) | 5x120 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14 x 1.25 (bolts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 9.5J–11J | ET9–ET21 |
| Rear (staggered) | 10.5J–12J | ET27–ET42 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| XM 50e | B58B30, 2,998 cc | 350 kW (476 PS) | AWD, 2024 to present | |
| XM | S68B44, 4,395 cc | 480 kW (653 PS) | AWD, 2022 to 2025 | |
| XM Label | S68B44, 4,395 cc | 550 kW (748 PS) | AWD, 2023 to 2026 | |
| XM Label | S68B44, 4,395 cc | 550 kW (748 PS) | AWD, 2026 to present |
Source: BMW XM, de.wikipedia.org.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 1,413 BMW XM on UK roads, placing it in the top 27% of car models by volume across our fitment database.
That makes BMW XM wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Length | 5,110 mm |
| Width | 2,005 mm |
| Height | 1,755 mm |
| Wheelbase | 3,105 mm |
| Kerb weight | 2,692 to 2,815 kg |
Source: BMW XM, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | 5-door crossover SUV |
| Produced | 2023–2026 |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Powerful plug-in hybrid drivetrain options; Luxurious interior and exterior design; Advanced technology features
- Cons: High price point; Limited production runs for special editions
