What size wheels fit a Ford C-Max (Compact)?

Roughly 6.5J–9J (ET35–ET55).

How many Ford C-MAX are there on UK roads?

Approximately 101,984 Ford C-MAX are licensed in the UK, according to DfT VEH0124 vehicle-parc data (2025).

Ford C-MAX wheel fitment — Compact

By Torque, AIWheelTech vehicle & fitment specialist · 2010–2017

Ford C-MAX wheel fitment at a glance — The Ford C-Max (Compact) (2010–2017) uses a 5x108 bolt pattern, 63.4 mm centre bore, M12x1.5 nuts torqued to ~110 Nm. It accepts ~6.5J–9J wheels at ET35–ET55.

Overview

The Ford C-Max is a compact MPV produced by Ford Motor Company from 2003 to 2019, featuring a five-door design. The first generation (2003-2010) was built on the Ford C1 platform and assembled in Saarlouis, Germany. It aimed to compete with models like the Renault Megane Scenic but faced delays due to technical challenges in developing a 7-seater version. This generation introduced various petrol and diesel engines alongside manual and automatic transmission options, including CVT and Powershift dual-clutch transmissions.

Ford C-MAX wheel fitment

Ford C-MAX wheel fitment for the Ford C-Max (Compact) (2010–2017): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)	5x108
Centre bore	63.4 mm
Bolt / thread	M12x1.5 (nuts)
Wheel-bolt torque	110 Nm
Seat type	tapered
Factory setup	square
TPMS	direct

Aftermarket wheel sizes — read per position:

Position	Width	Offset
Front	6.5J–9J	ET35–ET55

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Ford C-MAX →Get them fitted (UK)

UK popularity & demand

~101,984 Ford C-MAX licensed on UK roads — top 4% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 101,984 Ford C-MAX on UK roads, placing it in the top 4% of car models by volume across our fitment database.

That makes Ford C-MAX wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

Variant	Engine	Fuel	Power	Drive
1.5 EcoBoost	1.5L I4	petrol	150 hp	FWD
1.6 EcoBoost	1.6L I4	petrol	150 hp	FWD
2.0 Duratec HE	2.0L I4	petrol	145 hp	FWD
2.0 Duratorq TDCi	2.0L I4	diesel	136 hp	FWD
1.8 Duratec HE	1.8L I4	petrol	125 hp	FWD
1.6 Duratec Ti-VCT	1.6L I4	petrol	115 hp	FWD
1.8 Duratorq TDCi	1.8L I4	diesel	115 hp	FWD
1.6 Duratec	1.6L I4	petrol	100 hp	FWD
1.5 Duratorq TDCi	1.5L I4	diesel	95 hp	FWD
1.6 Duratorq TDCi	1.6L I4	diesel	90 hp	FWD

Performance

Variant	Power	0–62 mph	Top speed
1.6 Duratec	100 hp

Dimensions

Length	4371 mm
Width	1825 mm
Height	1588 mm
Wheelbase	2640 mm
Kerb weight	1372 kg

Body styles & production

Body styles	5-door MPV
Produced	2010–2017

Trim levels

TrendZetecTitanium

History & notable variants

The first generation of C-Max underwent a facelift in December 2006, incorporating Ford's 'Kinetic Design' elements. In the US market, it was introduced as Ford's first hybrid-only line with the release of the C-Max Hybrid and Energi plug-in hybrid models in 2012. Production ended in the US from September 2017 to mid-2018 and ceased globally at Saarlouis in June 2019.

Reliability & owner notes

Pros: Large cargo space; Flexible seating configurations; Range of engine options
Cons: Limited availability in some markets; Some models faced fuel economy issues
Common issues: None explicitly mentioned
