What size wheels fit a Ford Galaxy (III)?

Roughly 6.5J–9.5J (ET35–ET55).

How many Ford Galaxy are there on UK roads?

Approximately 49,234 Ford Galaxy are licensed in the UK, according to DfT VEH0124 vehicle-parc data (2025).

Ford Galaxy wheel fitment — III

By Torque, AIWheelTech vehicle & fitment specialist · 2006–2015

The Ford Galaxy (III) (2006–2015) uses a 5x108 bolt pattern, 63.4 mm centre bore, M14x1.5 bolts torqued to ~150 Nm. It accepts ~6.5J–9.5J wheels at ET35–ET55. That is the short version of Ford Galaxy wheel fitment; the full picture is below.

Overview

The Ford Galaxy is a seven-seater car produced by Ford of Europe from June 1995 to April 2023. Considered in the motor industry to be a large multi-purpose vehicle (MPV), it was the first Ford-brand MPV produced and marketed outside of North America, currently in its third generation. Sharing its platform architecture with the Ford Mondeo, the Galaxy was developed alongside the Ford S-Max; the model line is slotted between the Connect and Custom variants of the Ford Tourneo/Transit model family.

Ford Galaxy wheel fitment

Start with the hub. The Ford Galaxy (III) spec table gives the bolt pattern and bore; the second table is the aftermarket window for Ford Galaxy wheel fitment.

Bolt pattern (PCD)	5x108
Centre bore	63.4 mm
Bolt / thread	M14x1.5 (bolts)
Wheel-bolt torque	150 Nm
Seat type	tapered
Factory setup	square
TPMS	direct

Aftermarket wheel sizes — read per position:

Position	Width	Offset
Front	6.5J–9.5J	ET35–ET55

Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.

Browse wheels that fit a Ford Galaxy →Get them fitted (UK)

UK popularity & demand

~49,234 Ford Galaxy licensed on UK roads — top 6% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 49,234 Ford Galaxy on UK roads, placing it in the top 6% of car models by volume across our fitment database.

With that many on the road, Ford Galaxy wheel fitment is a spec fitters see constantly. We keep it current for that reason.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

Variant	Engine	Fuel	Power	Drive, years
1.6 L EcoBoost turbo I4		petrol
2.0 L Duratec I4		petrol
2.0 L EcoBoost turbo I4		petrol
2.3 L Duratec I4		petrol
1.8 L Duratorq TDCi I4		diesel
2.0 L Duratorq TDCi I4		diesel
2.2 L Duratorq TDCi I4		diesel

Source: Ford Galaxy, en.wikipedia.org.

Dimensions

Length	4,820 mm
Width	1,885 to 1,930 mm
Height	1,725 mm
Wheelbase	2,850 mm
Kerb weight	1,697 to 1,841 kg

Source: Ford Galaxy, en.wikipedia.org.

Body styles & production

Produced

2006–2015

Trim levels

AspenGLXGhiaUltimaLXZetecSilver

Factory colours

Candy Red MetallicDeep Impact Blue MetallicBrisbane Brown / Lunar Sky MetallicTango / Red Metalliccedar/blue met.Pepper Red PearlPanther Black Micac candy red met.Med.steel Blue Metallicsolar silver met.ingot silver met.

History & notable variants

The first generation (V191) was designed as a joint venture product between Ford and Volkswagen Group. Produced at AutoEuropa in Portugal, it used predominantly VW mechanicals but had a mix of both Ford and VW components inside. The MkI Galaxy received a facelift in 2000 with new exterior styling including New Edge design elements and an updated dashboard. In the UK, despite being rated as the least satisfying car by Top Gear in 1999, it was also the best-selling MPV that year.

Reliability & owner notes

Pros: First Ford-brand MPV outside North America; developed alongside the S-Max
Cons: Initial public reaction was negative in the UK despite being best-selling MPV
Common issues: Not specified
