Ford Kuga wheel fitment — I
Ford Kuga wheel fitment
Ford Kuga wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the Ford Kuga (I) (2008–present).
| Bolt pattern (PCD) | 5x108 |
| Centre bore | 63.4 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Wheel-bolt torque | 100 Nm |
| Seat type | tapered |
| Factory setup | square |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–9J | ET35–ET53 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Overview
The first generation of the Ford Kuga is a compact crossover SUV (C-segment) manufactured by Ford since 2008 for the European market. It was built at Ford's plant in Saarlouis, Germany and offered both front-wheel drive and all-wheel drive options. The car was based on the C1 platform shared with the Ford Focus and Ford C-Max. In the UK, only high-end Zetec and Titanium specifications were available. This generation marked a shift towards premium market aspirations for the Kuga.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 376,406 Ford Kuga on UK roads, placing it in the top 1% of car models by volume across our fitment database.
With that many on the road, Ford Kuga wheel fitment is a spec fitters see constantly. We keep it current for that reason.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
History & notable variants
The first-generation Kuga made its world premiere at the Frankfurt Motor Show in September 2007 and went on sale in early 2008. A facelift was introduced by the end of 2010, after being revealed earlier that year. The car's name, 'Kuga', means plague in Bosnian, Croatian, Serbian, and Slovenian languages, which affected its sales negatively in these regions.
Body styles & production
| Produced | 2008–present |
Trim levels
Factory colours
Reliability & owner notes
- Pros: Based on the C1 platform shared with other Ford models; offered both front-wheel drive and all-wheel drive options.
- Cons: Sales were negatively impacted by unfortunate naming in certain regions due to the meaning of 'Kuga' in local languages.
- Common issues: Not specified for this generation.
