Ford Mustang Gt wheel fitment — Vii LAE
Ford Mustang Gt wheel fitment at a glance: The Ford Mustang Gt (Vii) LAE (2015–2022) uses a 5x114.3 bolt pattern, 70.6 mm centre bore, M14x1.5 bolts torqued to ~108 Nm. It accepts ~9J–9.5J wheels at ET30–ET45 front; staggered setups run 9.5J–11.5J rear (ET30–ET53).
Ford Mustang Gt wheel fitment
Start with the hub. The Ford Mustang Gt (Vii) LAE spec table gives the bolt pattern and bore; the second table is the aftermarket window for Ford Mustang Gt wheel fitment.
| Bolt pattern (PCD) | 5x114.3 |
| Centre bore | 70.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 108 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 9J–9.5J | ET30–ET45 |
| Rear (staggered) | 9.5J–11.5J | ET30–ET53 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
Dimensions
| Kerb weight | 1,692 to 1,901 kg |
Source: EU type-approval data (EEA).
Body styles & production
| Produced | 2015–2022 |
Factory colours
EbonySilver MetallicSchool Bus YellowGrabber BlueCompetition OrangeKe Luo La Duo HongAvalanche GrayDark Blue PearlVermilion RedAbsolute BlackDynamic Red MetallicTriple YellowGreen Envy PearlGuard MetallicHi Performance WhiteDeep Impact Blue MetallicMagnetic Metallic MatteMagnetic MetallicBlackKona Blue Pearl
