Ford Ranger wheel fitment — V 2AB, 2AZB 100mm Arch Kit
Overview
The Ford Ranger is a mid-size pickup truck marketed globally by Ford since its reintroduction in North America for the 2019 model year, using the T6 platform developed in-house by Ford Australia. It was manufactured at the Michigan Assembly Plant in Wayne, Michigan and offered in two configurations: SuperCab (2+2 door with a 6-foot bed) and SuperCrew (4-door with a 5-foot bed). The Ranger is positioned below the F-150 in North America but serves as Ford's primary pickup offering outside of the Americas.
History & notable variants
The current generation of the Ford Ranger was reintroduced to North America after an eight-year hiatus, following its discontinuation in 2011. Developed on the T6 platform with adaptations for US regulations and local market demands, it marked a significant shift from previous generations by being larger than the compact pickup trucks that preceded it.
Ford Ranger wheel fitment
Everything below is what the fit-check uses for Ford Ranger wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Ford Ranger V 2AB, 2AZB 100mm Arch Kit.
| Bolt pattern (PCD) | 6x139.7 |
| Centre bore | 93.1 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Wheel-bolt torque | 140 Nm |
| Seat type | tapered |
| Factory setup | square |
| TPMS | none |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–10.5J | ET-3–ET55 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 2 Ford Ranger on UK roads, placing it in the top 87% of car models by volume across our fitment database.
A parc that size is why Ford Ranger wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Dimensions
| Kerb weight | 2,035 to 2,585 kg |
Source: EU type-approval data (EEA).
Body styles & production
| Produced | 2019–2023 |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Strong market presence globally; versatile configurations
- Cons: Limited availability in North America from 2011 to 2018
