What size wheels fit a Ford Tourneo Custom FAC, FCC?

Roughly 6.5J–8.5J (ET18–ET60).

How many Ford Tourneo Custom are there on UK roads?

Approximately 6,889 Ford Tourneo Custom are licensed in the UK, according to DfT VEH0124 vehicle-parc data (2025).

Ford Tourneo Custom wheel fitment — FAC, FCC

By Torque, AIWheelTech vehicle & fitment specialist · 2012–present

Quick answer on Ford Tourneo Custom wheel fitment: The Ford Tourneo Custom FAC, FCC (2012–present) uses a 5x160 bolt pattern, 65.1 mm centre bore, M14x1.5 bolts torqued to ~160 Nm. It accepts ~6.5J–8.5J wheels at ET18–ET60.

Ford Tourneo Custom wheel fitment

Ford Tourneo Custom wheel fitment for the Ford Tourneo Custom FAC, FCC (2012–present): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)	5x160
Centre bore	65.1 mm
Bolt / thread	M14x1.5 (bolts)
Wheel-bolt torque	160 Nm
Seat type	tapered
Factory setup	square
TPMS	direct

Aftermarket wheel sizes — read per position:

Position	Width	Offset
Front	6.5J–8.5J	ET18–ET60

As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Ford Tourneo Custom →Get them fitted (UK)

UK popularity & demand

~6,889 Ford Tourneo Custom licensed on UK roads — top 16% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 6,889 Ford Tourneo Custom on UK roads, placing it in the top 16% of car models by volume across our fitment database.

With that many on the road, Ford Tourneo Custom wheel fitment is a spec fitters see constantly. We keep it current for that reason.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Overview

The Ford Transit Custom is a mid-sized front-wheel-drive van produced by Ford Europe since 2012. It marks a split in the Transit range, with the Custom being the smaller version and the larger Ford Transit. The passenger versions of this vehicle are branded as Tourneo Custom.

Dimensions

Length	4972 mm
Width	1986 mm
Height	1922 mm
Wheelbase	2933 mm
Kerb weight	1786 kg

Body styles & production

Body styles	Van, Crew cab van, Minivan/Minibus
Produced	2012–present

Engines & drivetrain

Variant	Engine	Fuel	Power	Drive
2.0L EcoBlue	2.0L Ford EcoBlue I4 turbodiesel	diesel	136 hp	FWD
2.0L EcoBlue AWD	2.0L Ford EcoBlue I4 turbodiesel	diesel	136 hp	AWD
2.0L EcoBlue AWD Active	2.0L Ford EcoBlue I4 turbodiesel	diesel	136 hp	AWD
2.5L Duratec PHEV	2.5L Ford Duratec I4 petrol hybrid		103 hp	FWD
E-Transit Custom (EV)	NMC battery electric motor(s)	electric	100 hp	RWD
1.0L EcoBoost PHEV	1.0L Ford EcoBoost I3 petrol turbo hybrid		92 hp	FWD

Performance

Variant	Power	0–62 mph	Top speed
1.0L EcoBoost PHEV	92 hp	7.8 s	115 mph
2.0L EcoBlue AWD	136 hp	8.9 s	115 mph
2.0L EcoBlue AWD Active	136 hp	8.9 s	115 mph
E-Transit Custom (EV)	100 hp	7.4 s	89 mph

Trim levels

Tourneo CustomNugget

Factory colours

Frozen White (YZ)Magnetic Grey (H3)Race Red (RR)

History & notable variants

Unveiled at the 2012 Commercial Vehicle Show in Birmingham, England, the Transit Custom was not initially available in the United States or Canada but is sold in Mexico. It entered the Chinese market in 2016 and received a mild styling update with new engine options in 2017. In 2019, Ford introduced a mild hybrid system for EcoBlue engines and a plug-in hybrid version of the Tourneo Custom.

Reliability & owner notes

Pros: Mid-size, front-wheel-drive van; available in various body styles including passenger versions branded as Tourneo Custom.
Cons: Not initially available in the United States and Canada; production figures not provided.
