Ford Transit Connect wheel fitment — SKN
Ford Transit Connect wheel fitment
Ford Transit Connect wheel fitment for the Ford Transit Connect SKN (2002–present): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 57.1 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 100 Nm |
| Seat type | tapered |
| Factory setup | square |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6J–8.5J | ET35–ET50 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 135 Ford Transit Connect on UK roads, placing it in the top 50% of car models by volume across our fitment database.
That makes Ford Transit Connect wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Overview
The Ford Transit Connect SKN (second generation) is a compact panel van manufactured by Ford of Europe. Introduced in September 2012, it was designed to replace the first-generation model and features an updated Kinetic Design language with optional rear liftgate alongside double doors preferred by commercial buyers and wheelchair users. The vehicle includes MyKey technology for personalized key programming. Production took place at Valencia, Spain, and was imported into North America as a passenger van to circumvent import tariffs on light trucks. In North America, it offered two wheelbases and seating configurations up to seven passengers.
Body styles & production
| Produced | 2002–present |
Trim levels
Factory colours
History & notable variants
In 2014, the second-generation Transit Connect underwent its first redesign since 2002 with updates including a new front fascia and MyKey technology. A mid-life update in 2019 saw further design changes and the introduction of an 8-speed automatic transmission paired with either a 2.0L GDI or 1.5L EcoBlue diesel engine (the latter was later abandoned for North America). The model line ended production in North America after the 2023 model year.
Reliability & owner notes
- Pros: Compact design, efficient fuel consumption, MyKey technology for personalized key programming
- Cons: Limited engine options in North America after 2019 (diesel option abandoned)
- Common issues: Recalled in 2017 due to risk of engine fires caused by lack of coolant circulation
