What size wheels fit a Ford Transit F..6?

Roughly 5.5J–7.5J (ET40–ET60).

How many Ford Transit Custom are there on UK roads?

Approximately 4,245 Ford Transit Custom are licensed in the UK, according to DfT VEH0124 vehicle-parc data (2025).

Ford Transit Custom wheel fitment — F..6

By Torque, AIWheelTech vehicle & fitment specialist · 2012–present

Before you buy wheels, the Ford Transit Custom wheel fitment facts: The Ford Transit F..6 (2012–present) uses a 5x160 bolt pattern, 65.1 mm centre bore, M14x2.0 nuts torqued to ~140 Nm. It accepts ~5.5J–7.5J wheels at ET40–ET60.

Ford Transit Custom wheel fitment

Ford Transit Custom wheel fitment for the Ford Transit F..6 (2012–present): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)	5x160
Centre bore	65.1 mm
Bolt / thread	M14x2.0 (nuts)
Wheel-bolt torque	140 Nm
Seat type	tapered
Factory setup	square
TPMS	direct

Aftermarket wheel sizes — read per position:

Position	Width	Offset
Front	5.5J–7.5J	ET40–ET60

Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.

Browse wheels that fit a Ford Transit Custom →Get them fitted (UK)

UK popularity & demand

~4,245 Ford Transit Custom licensed on UK roads — top 20% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 4,245 Ford Transit Custom on UK roads, placing it in the top 20% of car models by volume across our fitment database.

A parc that size is why Ford Transit Custom wheel fitment is worth getting exactly right: a lot of owners are shopping for these numbers.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Overview

The Ford Transit Custom is a mid-sized front-wheel-drive van produced by Ford Europe since 2012, marking a split in the Transit range with the larger Ford Transit. It was unveiled at the Commercial Vehicle Show in Birmingham, England, and has been sold in Mexico but not initially in the United States or Canada. The first generation featured mild styling changes and new engine options over time.

Body styles & production

Produced

2012–present

Trim levels

Tourneo CustomFord New Transit (China)Ford Tourneo (Vietnam)

Factory colours

Red Pepper MetallicOcean PearlCafe MetallicMoondust Silver MetallicFrozen WhiteRoyalgrau MetallicSea Grey MetallicSea Gray MetallicBlue Turquoise MetallicChill MetallicDiamond WhiteAvalon MetallicPanther Black MetallicSchool Bus YellowKe Luo La Duo HongWildtrak Orange MicaDeep Impact Blue MetallicDark Blue PearlMidnight Sky PearlInk Blue Metallic

History & notable variants

The Transit Custom was introduced in 2012 and underwent updates including a new engine family in 2017 to comply with Euro 6 emissions standards. In 2019, it received an optional mild hybrid system and a plug-in hybrid version of the Tourneo variant was launched.

Reliability & owner notes

Pros: Compliant with Euro 6 emissions standards, mild hybrid and plug-in hybrid options available
Cons: Not initially sold in the United States or Canada
