Ford Transit FDD side profile — Ford Transit wheel fitment

Ford Transit wheel fitment — FDD

By Torque, AIWheelTech vehicle & fitment specialist · 1965–present
Ford Transit wheel fitment at a glance: The Ford Transit FDD (1965–present) uses a 5x160 bolt pattern, 65.1 mm centre bore, M14x1.5 bolts. It accepts ~6.5J–8J wheels at ET44–ET60.

Overview

The Ford Transit is a family of light commercial vehicles manufactured by the Ford Motor Company since 1965. This generation specifically refers to the model produced from 2015 onwards in North America, replacing the Ford E-Series van. The vehicle is available as a cargo van, passenger van (marketed as the Ford Tourneo), minibus, cutaway chassis, and pickup truck. It has been successful in North America since its introduction, quickly becoming the best-selling van of any type in the United States, including minivans. This generation features advanced technology and improved fuel efficiency compared to previous models.

History & notable variants

The current generation of Ford Transit was introduced in 2015 for the North American market as a replacement for the E-Series vans. It marks a significant shift from the earlier European-focused designs, adapting to meet specific needs of the North American commercial vehicle market. The model has been well-received and continues to dominate sales.

Ford Transit wheel fitment

Everything below is what the fit-check uses for Ford Transit wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Ford Transit FDD.

Bolt pattern (PCD)5x160
Centre bore65.1 mm
Bolt / threadM14x1.5 (bolts)
Seat typetapered
Factory setupsquare
TPMSdirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6.5J–8JET44–ET60

Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.

Browse wheels that fit a Ford Transit →Get them fitted (UK)

UK popularity & demand

~2,083 Ford Transit licensed on UK roads — top 24% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 2,083 Ford Transit on UK roads, placing it in the top 24% of car models by volume across our fitment database.

That makes Ford Transit wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Dimensions

Kerb weight2,136 to 2,935 kg

Source: EU type-approval data (EEA).

Body styles & production

Produced1965–present

Factory colours

Deep Impact Blue MetallicBrisbane Brown / Lunar Sky MetallicPepper Red PearlTango / Red Metalliccedar/blue met.saffron yellow transitPanther Black Micaw jewel green metMed.steel Blue Metallicwedgw00d blue transitOxford WhiteAgate Black MetallicCarbonized Gray MetallicCarbonized GrayBlackWhite Platinum TricoatMagnetic MetallicIngot Silver MetallicAbsolute Black PearlSterling Gray Metallic (Cladding)

Trim levels

not explicitly listed
