Kia Carens wheel fitment — FC
Overview
The third generation Kia Carens, also known as RP, debuted at the 2012 Paris Motor Show. It was manufactured from March 2013 to 2019 and offered in both five-seat and seven-seat configurations. The model featured a range of engine options including petrol and diesel variants paired with manual or automatic transmissions. Sales began in South Korea in March 2013, followed by other markets worldwide. In North America, the third generation Kia Rondo was only available in Canada after discontinuation in the United States due to slow sales.
Kia Carens wheel fitment
Start with the hub. The Kia Carens FC spec table gives the bolt pattern and bore; the second table is the aftermarket window for Kia Carens wheel fitment.
| Bolt pattern (PCD) | 4x114.3 |
| Centre bore | 67.1 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Seat type | tapered |
| Factory setup | square |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 5.5J–8J | ET30–ET45 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 12,776 Kia Carens on UK roads, placing it in the top 13% of car models by volume across our fitment database.
That makes Kia Carens wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Body styles & production
| Produced | 2013–2014 |
Trim levels
Factory colours
History & notable variants
In September 2016, a minor facelift was introduced with updated exterior styling and enhanced features such as an enlarged 'Tiger Nose' grille, retuned diesel engine for improved performance, and the addition of a seven-speed dual-clutch transmission. The Carens also received marketing collaborations like cross-promotion with DreamWorks Animation's film 'The Croods'.
Reliability & owner notes
- Pros: Updated exterior styling; Enhanced safety features
- Cons: Limited availability in North America
- Common issues: No specific reliability issues mentioned
