Kia Clarus wheel fitment — GC
If you only need the numbers for Kia Clarus wheel fitment: The Kia Clarus GC (1996–1999) uses a 4x114.3 bolt pattern, 67.1 mm centre bore, M12x1.5 nuts. It accepts ~5.5J–7.5J wheels at ET32–ET45.
Kia Clarus wheel fitment
Kia Clarus wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the Kia Clarus GC (1996–1999).
| Bolt pattern (PCD) | 4x114.3 |
| Centre bore | 67.1 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Seat type | tapered |
| Factory setup | square |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 5.5J–7.5J | ET32–ET45 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Body styles & production
| Produced | 1996–1999 |
Factory colours
Super-SilverRoyal Blue Mica MetallicOlive Green Pearl Metallicv3 opal grey met.RedClear-WhiteSilverGarnet-PearlOlive-SepiaCrimson-RedBrave-BlueElegant-BeigeBronze-BeigeEbony-BlackChrome-YellowCrystal-White
