Kia Km wheel fitment — Ii JE, JES
Kia Km wheel fitment in one line: The Kia Km (Ii) JE, JES (2005–2010) uses a 5x114.3 bolt pattern, 67.1 mm centre bore, M12x1.5 nuts. It accepts ~6.5J–9J wheels at ET25–ET46 front; staggered setups run 9.5J–9.5J rear (ET30–ET36).
Kia Km wheel fitment
Everything below is what the fit-check uses for Kia Km wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Kia Km (Ii) JE, JES.
| Bolt pattern (PCD) | 5x114.3 |
| Centre bore | 67.1 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–9J | ET25–ET46 |
| Rear (staggered) | 9.5J–9.5J | ET30–ET36 |
As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
Dimensions
| Kerb weight | 1,542 to 1,842 kg |
Source: EU type-approval data (EEA).
Body styles & production
| Produced | 2005–2010 |
Factory colours
Volcanic Red MetallicEver Green MicaSmoky Brown MetallicStone Beige MetallicBlack Cherry MetallicDark Grey MetallicDiamond Silver MetallicEbony BlackGreysh Purple MetallicIndigo Blue MetallicSmart Blue MetallicGreyish Silver MetallicSatin Silver MetallicClear White SolidVr Solid Red SolidClear WhiteGlacier WhiteRoyal Jade Green PearlOlive Green MetallicClear Silver Metallic
