Kia Opirus wheel fitment — LD
If you only need the numbers for Kia Opirus wheel fitment: The Kia Opirus LD (2003–2009) uses a 5x114.3 bolt pattern, 67.1 mm centre bore, M12x1.5 nuts torqued to ~100 Nm. It accepts ~6.5J–8J wheels at ET30–ET46 front; staggered setups run 9J–9J rear (ET30–ET41).
Kia Opirus wheel fitment
Kia Opirus wheel fitment for the Kia Opirus LD (2003–2009): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x114.3 |
| Centre bore | 67.1 mm |
| Bolt / thread | M12x1.5 (nuts) |
| Wheel-bolt torque | 100 Nm |
| Seat type | tapered |
| Factory setup | staggered |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–8J | ET30–ET46 |
| Rear (staggered) | 9J–9J | ET30–ET41 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Dimensions
| Kerb weight | 1,813 to 1,925 kg |
Source: EU type-approval data (EEA).
Body styles & production
| Produced | 2003–2009 |
Factory colours
Bright Silver Metallicc cobalt blue met.=bicolored kia u4 / kia y7p dark red wine met.Clear Silver Metallic=bicolored kia j6 / kia y5w warm grey met.Pewter Beige Metallicv midnight grey met.Midnight Black MetallicDiamond Silver MetallicClear WhiteCream Gold MetallicDark Rose Red MetallicPearl White
