What size wheels fit a Kia Sportage (Ii) JE, JES?

Roughly 6.5J–9J (ET30–ET46); staggered setups run 9.5J–9.5J rear.

How many Kia Sportage are there on UK roads?

Approximately 420,465 Kia Sportage are licensed in the UK, according to DfT VEH0124 vehicle-parc data (2025).

Kia Sportage wheel fitment — Ii JE, JES

By Torque, AIWheelTech vehicle & fitment specialist · 1993–present

Quick answer on Kia Sportage wheel fitment: The Kia Sportage (Ii) JE, JES (1993–present) uses a 5x114.3 bolt pattern, 67.1 mm centre bore, M12x1.5 nuts. It accepts ~6.5J–9J wheels at ET30–ET46 front; staggered setups run 9.5J–9.5J rear (ET34–ET36).

Kia Sportage wheel fitment

Kia Sportage wheel fitment comes down to two things: the factory hub spec, and how far the aftermarket width and offset can move from it. Both are here for the Kia Sportage (Ii) JE, JES (1993–present).

Bolt pattern (PCD)	5x114.3
Centre bore	67.1 mm
Bolt / thread	M12x1.5 (nuts)
Seat type	tapered
Factory setup	staggered
TPMS	direct

Aftermarket wheel sizes — read per position:

Position	Width	Offset
Front	6.5J–9J	ET30–ET46
Rear (staggered)	9.5J–9.5J	ET34–ET36

Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.

Browse wheels that fit a Kia Sportage →Get them fitted (UK)

Overview

The Kia Sportage (II) JE/JES is the second generation of this compact crossover SUV, transitioning from a body-on-frame to a car-based platform in 2004. It was developed alongside the Hyundai Tucson and shares its platform with the first-generation model. This generation saw improvements in fit and finish quality over its predecessor but faced criticism for being larger and less capable off-road compared to the original Sportage. Production began in Slovakia from 2006 onwards, following a two-year hiatus after the first generation.

Engines & drivetrain

Variant	Engine	Fuel	Power	Drive, years
2.0 ( G4GC )	1,975 cc	petrol	141 hp	2004 to 2010
2.7 ( G6BA )	2,656 cc	petrol	175 hp	2004 to 2010
2.0 ( D4EA )	1,991 cc	diesel	113 hp	2005 to 2010
2.0 CRDi	1,991 cc	diesel	150 hp	2008 to 2010
2.0 CRDi 4WD	1,991 cc	diesel	140 hp	2006 to 2010

Source: Kia Sportage, en.wikipedia.org.

UK popularity & demand

~420,465 Kia Sportage licensed on UK roads — top 1% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 420,465 Kia Sportage on UK roads, placing it in the top 1% of car models by volume across our fitment database.

With that many on the road, Kia Sportage wheel fitment is a spec fitters see constantly. We keep it current for that reason.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

History & notable variants

The second generation was introduced in 2005 with minor updates until May 2008 when it received its first facelift. A second UK-specific facelift followed early in 2009. The Sportage earned recognition for reliability and affordability, ranking highly in consumer reports.

Dimensions

Length	4,350 mm
Width	1,820 to 1,840 mm
Height	1,695 to 1,730 mm
Wheelbase	2,630 mm
Kerb weight	1,542 to 2,170 kg

Source: Kia Sportage, en.wikipedia.org; EU type-approval data (EEA).

Body styles & production

Produced

1993–present

Trim levels

JEJES

Factory colours

b red pearl met.Clear White SolidBlack Metallicl vert jade met.Bright Silver Metallicg jade green prl.met.h volcanic red met.p volcanic red met.y soft gold met.Great Prl. Red MetallicByte Blue Metallic

Reliability & owner notes

Pros: Improved quality and fit/finish compared to the first generation; Available V6 engine option
Cons: Larger size than original Sportage; Less off-road capability
