Mercedes Citan wheel fitment — / T Class MFK
Overview
The Mercedes-Benz Citan is a panel van and leisure activity vehicle introduced as a badge-engineered variant of the Renault Kangoo in 2012. It is marketed by Mercedes-Benz as the successor to the Vaneo compact MPV, being the smallest model offered alongside the mid-size Vito (aka Viano, V-Class, and EQV) and large Sprinter. The Citan was assembled by Renault subsidiary MCA in Maubeuge, France, from 2012 until its discontinuation in 2021.
Mercedes Citan wheel fitment
Mercedes Citan wheel fitment for the Mercedes Citan / T Class MFK (2013–2023): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x114.3 |
| Centre bore | 66.1 mm |
| Bolt / thread | M12x1.5 (bolts) |
| Wheel-bolt torque | 108 Nm |
| Seat type | tapered |
| Factory setup | square |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6J–8.5J | ET25–ET45 |
As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 915 Mercedes Citan on UK roads, placing it in the top 31% of car models by volume across our fitment database.
That makes Mercedes Citan wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive |
|---|---|---|---|---|
| eCitan / EQT | Electric motor with 44kWh battery | electric | 121 hp | FWD |
| 1.3 H5Ht/M282 | Nissan HR engine (HR13DDT) 1.332L I4 turbo petrol | petrol | 102 hp | FWD |
| 1.5 OM607 | Renault K-Type (K9K/OM607) 1.461L I4 turbo diesel | diesel | 75 hp | FWD |
Performance
| Variant | Power | 0–62 mph | Top speed |
|---|---|---|---|
| eCitan / EQT | 121 hp | 87 mph |
Dimensions
| Length | 3937 mm |
| Width | 1829 mm |
| Height | 1809 mm |
| Wheelbase | 2697 mm |
| Kerb weight | 1295 kg |
Body styles & production
| Body styles | Panel Van, Dualiner, Traveliner |
| Produced | 2013–2023 |
Trim levels
History & notable variants
The first generation of the Mercedes-Benz Citan (W415) was launched as a result of Daimler's partnership with the Renault-Nissan-Mitsubishi Alliance. It aimed to cater to both passenger car and light commercial vehicle markets, marking Mercedes-Benz’s return to this segment since 1995. The model received safety improvements after initial Euro NCAP testing in April 2013, achieving a four-star rating for its Traveliner variant later on.
Reliability & owner notes
- Pros: Badge-engineered Renault Kangoo with Mercedes-Benz quality and branding
- Cons: Limited performance compared to other models in its class
