Mercedes Citan Tourer / T-class side profile — Mercedes Citan wheel fitment

Mercedes Citan wheel fitment — Tourer / T-class

By Torque, AIWheelTech vehicle & fitment specialist · 2013–2023
Mercedes Citan wheel fitment at a glance — The Mercedes Citan Tourer / T-class (2013–2023) uses a 5x114.3 bolt pattern, 66.1 mm centre bore, M12x1.5 bolts torqued to ~108 Nm. It accepts ~6J–8.5J wheels at ET25–ET45.

Overview

The Mercedes-Benz Citan Tourer / T-Class is the second generation of the Mercedes-Benz Citan series, introduced in 2021. It is based on the third-generation Renault Kangoo and uses the CMF-CD platform. The vehicle comes as a panel van and leisure activity vehicle (Tourer), replacing the previous Citan Traveliner model. Assembled by Renault subsidiary MCA in Maubeuge, France, it targets both passenger car and light commercial vehicle markets.

Mercedes Citan wheel fitment

Mercedes Citan wheel fitment for the Mercedes Citan Tourer / T-class (2013–2023): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x114.3
Centre bore66.1 mm
Bolt / threadM12x1.5 (bolts)
Wheel-bolt torque108 Nm
Seat typetapered
Factory setupsquare
TPMSdirect

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front6J–8.5JET25–ET45

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Mercedes Citan →Get them fitted (UK)

UK popularity & demand

~915 Mercedes Citan licensed on UK roads — top 31% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 915 Mercedes Citan on UK roads, placing it in the top 31% of car models by volume across our fitment database.

That makes Mercedes Citan wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive
eCitan / EQTsynchronous with coiled rotor electric motorelectric121 hpFWD
1.3 H5Ht/M2821.332L H5Ht/M282 I4petrol102 hpFWD
1.5 OM6071.461L K9K/OM607 I4diesel75 hpFWD

Performance

VariantPower0–62 mphTop speed
eCitan / EQT121 hp87 mph

Dimensions

Length3937 mm
Width1829 mm
Height1809 mm
Wheelbase2697 mm
Kerb weight1295 kg

Body styles & production

Body stylesPanel Van, Tourer
Produced2013–2023

Trim levels

Tourer

Factory colours

Artikwess SolidAmarenarot Solidbornitrot met.Tintenblau Solidkornelitblau metpfeffergruenkieselgrauDelfingrau SolidBrillantsilber MetallicTenoritgrau MetallicKieselgrau SolidARKTIKWEISSBRILLANTSILBER-MET.TENORITGRAU-MET.GRAUCHESTNUT BRONZE-MET.FIRECRACKER RED

History & notable variants

The second generation of the Mercedes-Benz Citan was launched in August 2021 as a panel van and Tourer variant. In April 2022, the T-Class MPV version was released with seats for five people, while a long-wheelbase seven-seater model is planned. The vehicle received a Platinum rating from Euro NCAP in March 2024 due to its advanced safety features.

Reliability & owner notes
