Mercedes Citan wheel fitment — I
Overview
The Mercedes-Benz Citan is a panel van and leisure activity vehicle introduced in 2012 as a badge-engineered variant of the Renault Kangoo. It is marketed by Mercedes-Benz as the successor to the Vaneo compact MPV, making it the smallest model offered alongside the mid-size Vito (aka Viano, V-Class, and EQV) and large Sprinter. The Citan is assembled in Maubeuge, France, by Renault subsidiary MCA, alongside its twin, the Kangoo.
Mercedes Citan wheel fitment
Mercedes Citan wheel fitment for the Mercedes Citan (I) (2012–2026): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x108 |
| Centre bore | 60.1 mm |
| Bolt / thread | M12x1.5 (bolts) |
| Wheel-bolt torque | 108 Nm |
| Seat type | tapered |
| Factory setup | square |
| TPMS | direct |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6J–8.5J | ET8–ET45 |
As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.
UK popularity & demand
Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 915 Mercedes Citan on UK roads, placing it in the top 31% of car models by volume across our fitment database.
That makes Mercedes Citan wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.
Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive |
|---|---|---|---|---|
| eCitan / EQT | synchronous with coiled rotor electric motor | electric | 121 hp | FWD |
| 1.2L M200 | 1.197 cc M200 I4 | petrol | 114 hp | FWD |
| 1.3L H5Ht/M282 | 1,332 cc DOHC 16v I4 | petrol | 102 hp | FWD |
| 1.5L OM607 | 1.461 cc K9K/OM607 I4 | diesel | 75 hp | FWD |
| 1.5L K9K/OM607 | 1,461 cc SOHC 8v I4 | diesel | 75 hp | FWD |
Performance
| Variant | Power | 0–62 mph | Top speed |
|---|---|---|---|
| 1.5L OM607 | 75 hp | 83 mph | |
| 1.2L M200 | 114 hp | 83 mph | |
| 1.3L H5Ht/M282 | 102 hp | 97 mph | |
| 1.5L K9K/OM607 | 75 hp | 83 mph | |
| eCitan / EQT | 121 hp | 9.7 s | 84 mph |
Dimensions
| Length | 3937 mm |
| Width | 1829 mm |
| Height | 1809 mm |
| Wheelbase | 2697 mm |
| Kerb weight | 1295 kg |
Body styles & production
| Body styles | Panel Van, Dualiner, Traveliner |
| Produced | 2012–2026 |
Trim levels
Factory colours
History & notable variants
The first generation of the Mercedes-Benz Citan was launched as a result of Daimler's partnership with the Renault-Nissan-Mitsubishi Alliance. It aimed to cater to both passenger car and light commercial vehicle markets, marking the return of Mercedes-Benz in the commercial vehicle market since 1995. The model received a three-star rating from Euro NCAP initially but was later reassessed after safety improvements were made.
Reliability & owner notes
- Pros: Badge-engineered Renault Kangoo with Mercedes-Benz quality; Wide range of body styles and lengths; Strong marketing campaign featuring MacGyver
- Cons: Limited performance options compared to other models in the lineup; Initial safety ratings were lower than expected
