Mercedes Cl-Klasse 216 side profile — Mercedes CL-Class wheel fitment

Mercedes CL-Class wheel fitment — Cl-Klasse 216

By Torque, AIWheelTech vehicle & fitment specialist · 2007–2014
If you only need the numbers for Mercedes CL-Class wheel fitment: The Mercedes Cl-Klasse 216 (2007–2014) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts. It accepts ~8J–8.5J wheels at ET30–ET43 front; staggered setups run 8.5J–11J rear (ET27–ET45).

Mercedes CL-Class wheel fitment

Mercedes CL-Class wheel fitment for the Mercedes Cl-Klasse 216 (2007–2014): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Seat typeradius
Factory setupstaggered
TPMSdirect
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front8J–8.5JET30–ET43
Rear (staggered)8.5J–11JET27–ET45

Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.

Browse wheels that fit a Mercedes CL-Class →Get them fitted (UK)

Overview

The third generation Mercedes-Benz CL-Class (C216) was introduced in 2006, following a six-year development period. It continued the tradition of being a grand tourer with no B-pillar between front and rear side windows. Built on the chassis of the W221 S-Class but without V6 or hybrid engines available for this model, it offered four variants: CL 550 (CL 500 in some markets), high-performance CL 63 AMG, ultra-luxury twin-turbo CL 600, and top-of-the-line CL 65 AMG. The C216 was heavier than its S-Class counterpart but featured advanced technologies such as Distronic Plus cruise control and Active NightVision.

Dimensions

Kerb weight1,995 to 2,245 kg

Source: EU type-approval data (EEA).

Body styles & production

Produced2007–2014

Trim levels

CL 550CL 600CL 63 AMGCL 65 AMG

Factory colours

Obsidian Black MetallicBlack Diamond MetallicDesigno Silber MetallicDesigno Chromaflair MetallicMystic Blue PearlDesigno Mocha Black MetallicVaricolor III MetallicCashmere MetallicDesigno Mystic Red MetallicMystic White PearlDesigno Mauritiusblau MetallicChablis MetallicBlack Opal MetallicJade Green MetallicCapri Blue MetallicFlint Gray MetallicDeep Black, Tiefschwarz, BlackDesigno Graphite Green MetallicStorm Red MetallicBarolo Red Metallic

History & notable variants

The third generation of the Mercedes-Benz CL-Class (C216) made its debut at the Paris Motor Show in 2006, marking a significant evolution with improved safety features like Distronic Plus cruise control. In 2010, it received a facelift that included updated exterior and interior designs along with enhanced engine performance and new technologies such as Active Blind Spot Assist and Night View Assist Plus.

Reliability & owner notes
