Mercedes CLA-Class wheel fitment — Cla-Klasse 117, 245G
Overview
The first generation of the Mercedes-Benz CLA is a series of luxury subcompact executive cars manufactured since 2013, based on the platform of the W176 A-Class and W246 B-Class compact cars. It was introduced as a four-door sedan marketed as a four-door coupé and later expanded to include a Shooting Brake variant in 2015. The CLA is Mercedes-Benz's first front-wheel drive vehicle offered in the American market, positioned above the A-Class and nearly on par with the C-Class in terms of luxury and performance.
History & notable variants
The design of the C117 CLA was based on the Concept Style Coupe concept unveiled at various events in 2012. It was publicly unveiled at the 2013 North American International Auto Show, with sales commencing in September 2013. The vehicle underwent a facelift in 2017, introducing new restyled headlights and taillights with available bold LED lighting. Notable variants include the CLA Edition 1 (2013–2015) and the AMG CLA 45 (2013–2019).
Mercedes CLA-Class wheel fitment
Everything below is what the fit-check uses for Mercedes CLA-Class wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Mercedes Cla-Klasse 117, 245G.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M14x1.5 (bolts) |
| Wheel-bolt torque | 110 Nm |
| Seat type | radius |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 6.5J–7.5J | ET34–ET53 |
| Rear (staggered) | 8.5J–9J | ET35–ET50 |
Width and offset move together: roughly 8 to 10 ET more for every extra 1J keeps the wheel inside the arch. Final offset and any spacer come from the fit-check.
Engines & drivetrain
| Variant | Engine | Fuel | Power | Drive, years |
|---|---|---|---|---|
| CLA 180 BlueEFFICIENCY Edition | R4-Ottomotor, 1,595 cc, Motorkenndaten | petrol | 90 kW (122 PS) | FWD, 2013 to 2018 |
| CLA 180 | R4-Ottomotor, 1,595 cc, Motorkenndaten | petrol | 90 kW (122 PS) | FWD, 2013 to 2019 |
| CLA 200 | R4-Ottomotor, 1,595 cc, Motorkenndaten | petrol | 115 kW (156 PS) | FWD, 2013 to 2019 |
| CLA 220 4MATIC | R4-Ottomotor, 1,991 cc, Motorkenndaten | petrol | 135 kW (184 PS) | 4MATIC, 2016 to 2019 |
| CLA 250 | R4-Ottomotor, 1,991 cc, Motorkenndaten | petrol | 155 kW (211 PS) | FWD, 2013 to 2014 |
| CLA 250 | R4-Ottomotor, 1,991 cc, Motorkenndaten | petrol | 155 kW (211 PS) | FWD, 2014 to 2019 |
| CLA 250 Sport | R4-Ottomotor, 1,991 cc, Motorkenndaten | petrol | 160 kW (218 PS) | FWD, 2014 to 2018 |
| CLA 250 4MATIC | R4-Ottomotor, 1,991 cc, Motorkenndaten | petrol | 155 kW (211 PS) | 4MATIC, 2013 to 2019 |
| CLA 250 Sport 4MATIC | R4-Ottomotor, 1,991 cc, Motorkenndaten | petrol | 160 kW (218 PS) | 4MATIC, 2014 to 2018 |
| CLA 45 AMG | R4-Ottomotor, 1,991 cc, Motorkenndaten | petrol | 265 kW (360 PS) | AWD, 2013 to 2015 |
| Mercedes-AMG CLA 45 | R4-Ottomotor, 1,991 cc, Motorkenndaten | petrol | 280 kW (381 PS) | AWD, 2015 to 2019 |
| CLA 180 CDI | R4-Dieselmotor, 1,461 cc, Motorkenndaten | diesel | 80 kW (109 PS) | FWD, 2013 to 2018 |
| CLA 200 CDI | R4-Dieselmotor, 1,796 cc, Motorkenndaten | diesel | 100 kW (136 PS) | FWD, 2013 to 2014 |
| CLA 200 CDI | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 100 kW (136 PS) | FWD, 2014 to 2019 |
| CLA 200 CDI 4MATIC | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 100 kW (136 PS) | 4MATIC, 2014 to 2019 |
| CLA 220 CDI | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 125 kW (170 PS) | FWD, 2013 to 2014 |
| CLA 220 CDI | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 125 kW (170 PS) | FWD, 2014 |
| CLA 220 CDI | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 125 kW (170 PS) | FWD, 2018 to 2019 |
| CLA 220 CDI | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 130 kW (177 PS) | FWD, 2014 to 2018 |
| CLA 220 CDI 4MATIC | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 125 kW (170 PS) | 4MATIC, 2014 |
| CLA 220 CDI 4MATIC | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 125 kW (170 PS) | 4MATIC, 2018 to 2019 |
| CLA 220 CDI 4MATIC | R4-Dieselmotor, 2,143 cc, Motorkenndaten | diesel | 130 kW (177 PS) | 4MATIC, 2014 to 2018 |
Source: Mercedes-Benz Baureihe 117, de.wikipedia.org.
Dimensions
| Length | 4,630 to 4,669 mm |
| Width | 1,777 mm |
| Height | 1,416 to 1,435 mm |
| Wheelbase | 2,699 mm |
| Kerb weight | 1,395 to 1,615 kg |
Source: Mercedes-Benz Baureihe 117, de.wikipedia.org; EU type-approval data (EEA).
Body styles & production
| Body styles | Limousine, Kombi |
| Produced | 2012–2019 |
| Units produced | 750,000 |
Factory colours
Trim levels
Reliability & owner notes
- Pros: Luxurious interior, advanced safety features, strong performance variants
- Cons: Less practical than the A-Class it is based on, higher fuel consumption for some models
