Mercedes E Class Amg 211, 211AMG side profile — Mercedes E Class AMG wheel fitment

Mercedes E Class AMG wheel fitment — 211, 211AMG

By Torque, AIWheelTech vehicle & fitment specialist · 2002–2009
Mercedes E Class AMG wheel fitment at a glance — The Mercedes E Class Amg 211, 211AMG (2002–2009) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~110 Nm. It accepts ~8J–9J wheels at ET25–ET38 front; staggered setups run 8.5J–11J rear (ET25–ET40).

Overview

The Mercedes-Benz E-Class W211 generation was launched in 2002 as an evolution of its predecessor. It offered significant improvements over earlier models with a focus on addressing quality and technical issues raised by previous versions. The W211-based C219 CLS-Class four-door coupe was introduced in 2005 to attract younger buyers, while the E-Class received a facelift in June 2006 for the 2007 model year, introducing features like Pre-Safe (without brake support) as standard and dropping Sensotronic. The largest factory-built engine in this range was the E500 with its engine size increased to 5.5 liters.

Mercedes E Class AMG wheel fitment

Mercedes E Class AMG wheel fitment for the Mercedes E Class Amg 211, 211AMG (2002–2009): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque110 Nm
Seat typeradius
Factory setupstaggered
TPMSdirect
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front8J–9JET25–ET38
Rear (staggered)8.5J–11JET25–ET40

As a rule, each extra 1J of width wants roughly +8–10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Mercedes E Class AMG →Get them fitted (UK)

UK popularity & demand

~210,627 Mercedes E Class AMG range licensed on UK roads — top 2% of models by volume.

Based on DfT VEH0124 vehicle-parc data (2025), there are approximately 210,627 Mercedes E Class AMG range on UK roads, placing it in the top 2% of car models by volume across our fitment database.

That makes Mercedes E Class AMG wheel fitment a high-demand spec to keep in stock. It is one reason we track it here.

Source: DfT/DVLA licensed-vehicle statistics (VEH0124), matched to the AIWheelTech fitment database.

Engines & drivetrain

VariantEngineFuelPowerDrive
E 63 AMG6.2L M156 V8 petrolpetrol500 hpRWD
E 63 AMG (AWD)6.2L M156 V8 petrolpetrol500 hp4Matic
E 55 AMG5.4L M113 V8 petrolpetrol469 hpRWD
E 55 AMG (AWD)5.4L M113 V8 petrolpetrol469 hp4Matic
E 500 AMG5.0L M112 V8 petrolpetrol388 hpRWD
E 500 AMG (AWD)5.0L M112 V8 petrolpetrol388 hp4Matic
E 350 CGI3.5L M272 V6 petrolpetrol306 hpRWD
E 350 CGI (AWD)3.5L M272 V6 petrolpetrol306 hp4Matic
E 200 CGI1.8L M270 turbo petrolpetrol184 hpRWD
E 200 CGI (AWD)1.8L M270 turbo petrolpetrol184 hp4Matic
E 270 CDI2.1L OM642 turbo dieseldiesel163 hpRWD
E 270 CDI BlueEFFICIENCY2.1L OM642 turbo dieseldiesel163 hpRWD
E 270 CDI BlueEFFICIENCY (AWD)2.1L OM642 turbo dieseldiesel163 hp4Matic

Performance

VariantPower0–62 mphTop speed
E 270 CDI163 hp8.5 s139 mph
E 270 CDI BlueEFFICIENCY163 hp8.5 s139 mph
E 270 CDI BlueEFFICIENCY (AWD)163 hp8.5 s137 mph
E 200 CGI184 hp7.5 s149 mph
E 200 CGI (AWD)184 hp7.5 s149 mph
E 350 CGI306 hp5.8 s155 mph
E 350 CGI (AWD)306 hp5.8 s155 mph
E 500 AMG388 hp4.9 s155 mph
E 500 AMG (AWD)388 hp4.9 s155 mph
E 55 AMG469 hp4.7 s155 mph
E 55 AMG (AWD)469 hp4.7 s155 mph
E 63 AMG500 hp4.4 s155 mph
E 63 AMG (AWD)500 hp4.4 s155 mph

Body styles & production

Body stylesSaloon, Touring (estate), Coupé
Produced2002–2009

Trim levels

E200 CGIE230 CGIE500

Factory colours

Obsidian Black MetallicBlack , Deep Black , TiefschwarzDesigno Graphite Green MetallicDesigno Bronze MetallicChablis MetallicFirnweissDesigno Purpur MicaAtlasgrau Metallic Matte - Low GlossJade Black MetallicBlack Opal MetallicCopper MetallicBlack Diamond MetallicDark Turquoise Metallic , Circongruen MicaDesigno Meerblau MetallicSilver Metallic , Designo Silber MetallicGold MetallicDesigno Chromaflair MetallicMystic Blue PearlDesigno Mocha Black MetallicViolan Metallic

History & notable variants

The W211 generation of the Mercedes-Benz E-Class saw significant changes from its predecessor, including addressing quality issues and introducing advanced safety features like Pre-Safe. It also introduced AMG models badged as E55 and E63, alongside other tuning house installations. The facelift in 2006 marked a turning point with improved engine specifications and enhanced standard equipment.

Reliability & owner notes
