Mercedes Amg G 63 463A side profile — Mercedes G-Class AMG wheel fitment

Mercedes G-Class AMG wheel fitment — G 63 463A

By Torque, AIWheelTech vehicle & fitment specialist · 1979–present
Mercedes G-Class AMG wheel fitment at a glance: The Mercedes Amg G 63 463A (1979–present) uses a 5x130 bolt pattern, 84.1 mm centre bore, M14x1.5 bolts torqued to ~180 Nm. It accepts ~7.5J–11.5J wheels at ET-32–ET52.

Overview

The Mercedes-Benz G-Class, also known colloquially as the G-Wagon or G-Wagen (abbreviation of Geländewagen), is a luxury SUV produced by Mercedes-Benz. Originally developed in 1972 for military use and later introduced to civilian markets in 1979, it has evolved into one of Daimler's longest-running models. The second generation W463 was launched in 2018 with significant updates including a revised chassis, powertrain, body design, and interior features. This model is manufactured at the Magna Steyr plant in Graz, Austria, and continues to be highly regarded for its robust construction, three locking differentials, and luxurious appointments.

Mercedes G-Class AMG wheel fitment

Start with the hub. The Mercedes Amg G 63 463A spec table gives the bolt pattern and bore; the second table is the aftermarket window for Mercedes G-Class AMG wheel fitment.

Bolt pattern (PCD)5x130
Centre bore84.1 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque180 Nm
Seat typeradius
Factory setupsquare
TPMSdirect
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front7.5J–11.5JET-32–ET52

As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Mercedes G-Class AMG →Get them fitted (UK)

Dimensions

Kerb weight2,429 to 2,685 kg

Source: EU type-approval data (EEA).

Body styles & production

Produced1979–present

Trim levels

G 63 AMG

Factory colours

Obsidian Black MetallicBlack, Deep Black, TiefschwarzDesigno Graphite Green MetallicDesigno Platinum Black MetallicPlatin Metallic MatteDesigno Mysticbraun MetallicDesigno Nachtschwarz Metallic MattePolar WhiteSouth Seas Blue MetallicMagnetitschwarz MetallicDesigno Olive PearlDesigno Meerblau MetallicCitrine Brown Metallic MatteSelenitgrau Metallic MatteJade Green MetallicMystic Blue PearlDesigno Mocha Black MetallicPlatinum Blue MetallicFlint Gray MetallicWuestensand, Desert Sand

History & notable variants

In 2018, Mercedes-Benz introduced the second-generation W463 G-Class with substantial changes aimed at enhancing comfort and performance while maintaining its off-road capabilities. Notable updates include a new platform, improved powertrains, and enhanced interior technology. The model has received acclaim for its blend of luxury and ruggedness, continuing to attract enthusiasts and collectors alike.

Reliability & owner notes
