Mercedes GL-Class 166 side profile — Mercedes GL-Class wheel fitment

Mercedes GL-Class wheel fitment — 166

By Torque, AIWheelTech vehicle & fitment specialist · 2013–2016
Mercedes GL-Class wheel fitment in one line: The Mercedes GL-Class 166 (2013–2016) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~140 Nm. It accepts ~8.5J–11J wheels at ET28–ET62 front; staggered setups run 9.5J–9.5J rear (ET31–ET44).

Overview

The Mercedes-Benz GLS (formerly GL-Class) is a full-size luxury crossover SUV produced by Mercedes-Benz since 2006, positioned above the GLE in the marque's SUV lineup. The second generation model (X166), introduced in September 2012 and renamed to GLS in 2016 due to a rebranding initiative, is built on an unibody architecture shared with the GLE. It features efficiency improvements such as start-stop systems and drive-by-wire steering, alongside high-performance variants like the GL63 AMG.

History & notable variants

The second generation of the Mercedes-Benz GL-Class (X166) was introduced in September 2012 and underwent a facelift in 2016 when it was renamed to GLS. This model saw performance improvements, minor exterior and interior design changes, and the introduction of high-performance variants such as the GL63 AMG.

Mercedes GL-Class wheel fitment

Everything below is what the fit-check uses for Mercedes GL-Class wheel fitment: the factory bolt spec first, then the width and offset window that clears the arches and the brakes on the Mercedes GL-Class 166.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque140 Nm
Seat typeradius
Factory setupstaggered
TPMSdirect
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front8.5J–11JET28–ET62
Rear (staggered)9.5J–9.5JET31–ET44

Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.

Browse wheels that fit a Mercedes GL-Class →Get them fitted (UK)

Engines & drivetrain

VariantEngineFuelPowerDrive, years
ML 300 4MATICV6-Ottomotor, 3,498 cc, Motorkenndatenpetrol185 kW (252 PS)4MATIC, 2012 to 2015
ML 350 4MATICV6-Ottomotor, 3,498 cc, Motorkenndatenpetrol225 kW (306 PS)4MATIC, 2011 to 2014
ML 400 4MATICV6-Ottomotor, 2,996 cc, Motorkenndatenpetrol245 kW (333 PS)4MATIC, 2015
ML 500 4MATICV8-Ottomotor, 4,663 cc, Motorkenndatenpetrol300 kW (408 PS)4MATIC, 2012 to 2015
ML 63 AMGV8-Ottomotor, 5,461 cc, Motorkenndatenpetrol386 kW (525 PS)AWD, 2012 to 2015
ML 250 BlueTEC 4MATICR4-Dieselmotor, 2,143 cc, Motorkenndatendiesel150 kW (204 PS)4MATIC, 2011 to 2015
ML 350 BlueTEC 4MATICV6-Dieselmotor, 2,987 cc, Motorkenndatendiesel190 kW (258 PS)4MATIC, 2011 to 2015
GLE 320 4MATICV6-Ottomotor, 2,996 cc, Motorkenndatenpetrol200 kW (272 PS)4MATIC, 2015 to 2018
GLE 350V6-Ottomotor, 3,498 cc, Motorkenndatenpetrol225 kW (306 PS)RWD, 2015 to 2018
GLE 350 4MATICV6-Ottomotor, 3,498 cc, Motorkenndatenpetrol225 kW (306 PS)4MATIC, 2015 to 2018
GLE 400 4MATICV6-Ottomotor, 2,996 cc, Motorkenndatenpetrol245 kW (333 PS)4MATIC, 2015 to 2018
GLE 43 AMG 4MATICV6-Ottomotor, 2,996 cc, Motorkenndatenpetrol270 kW (367 PS)4MATIC, 2015 to 2017
GLE 43 AMG 4MATICV6-Ottomotor, 2,996 cc, Motorkenndatenpetrol287 kW (390 PS)4MATIC, 2017 to 2018
GLE 500 4MATICV8-Ottomotor, 4,663 cc, Motorkenndatenpetrol320 kW (435 PS)4MATIC, 2015
GLE 500 4MATICV8-Ottomotor, 4,663 cc, Motorkenndatenpetrol335 kW (455 PS)4MATIC, 2015 to 2018
GLE 500 eV6-Ottomotor + Elektromotor, 2,996 cc, Motorkenndatenpetrol245 kW (333 PS)AWD, 2015 to 2018
AMG GLE 63V8-Ottomotor, 5,461 cc, Motorkenndatenpetrol410 kW (557 PS)AWD, 2015 to 2018
AMG GLE 63 SV8-Ottomotor, 5,461 cc, Motorkenndatenpetrol430 kW (585 PS)AWD, 2015 to 2018
GLE 250 dR4-Dieselmotor, 2,143 cc, Motorkenndatendiesel150 kW (204 PS)RWD, 2015 to 2018
GLE 250 d 4MATICR4-Dieselmotor, 2,143 cc, Motorkenndatendiesel150 kW (204 PS)4MATIC, 2015 to 2018
GLE 350 d 4MATICV6-Dieselmotor, 2,987 cc, Motorkenndatendiesel190 kW (258 PS)4MATIC, 2015 to 2018

Source: Mercedes-Benz W 166, de.wikipedia.org.

Performance

VariantPower0 to 62 mph (0 to 100 km/h)Top speed
ML 300 4MATIC185 kW (252 PS)8.5 s235 km/h (146 mph)
ML 350 4MATIC225 kW (306 PS)7.6 s240 km/h (149 mph)
ML 400 4MATIC245 kW (333 PS)6.1 s247 km/h (153 mph)
ML 500 4MATIC300 kW (408 PS)5.6 s250 km/h (155 mph)
ML 63 AMG386 kW (525 PS)4.7 to 4.8 s250 to 280 km/h (155 to 174 mph)
ML 250 BlueTEC 4MATIC150 kW (204 PS)9 s210 km/h (130 mph)
ML 350 BlueTEC 4MATIC190 kW (258 PS)7.4 s224 km/h (139 mph)
GLE 320 4MATIC200 kW (272 PS)7.6 s230 km/h (143 mph)
GLE 350225 kW (306 PS)7.5 s240 km/h (149 mph)
GLE 350 4MATIC225 kW (306 PS)7.5 s240 km/h (149 mph)
GLE 400 4MATIC245 kW (333 PS)6.1 s247 km/h (153 mph)
GLE 43 AMG 4MATIC270 kW (367 PS)5.7 s250 km/h (155 mph)
GLE 43 AMG 4MATIC287 kW (390 PS)5.7 s250 km/h (155 mph)
GLE 500 4MATIC320 kW (435 PS)5.3 s250 km/h (155 mph)
GLE 500 4MATIC335 kW (455 PS)5.1 s250 km/h (155 mph)
GLE 500 e245 kW (333 PS)5.3 s245 km/h (152 mph)
AMG GLE 63410 kW (557 PS)4.3 s250 to 280 km/h (155 to 174 mph)
AMG GLE 63 S430 kW (585 PS)4.2 s250 to 280 km/h (155 to 174 mph)
GLE 250 d150 kW (204 PS)8.6 s210 km/h (130 mph)
GLE 250 d 4MATIC150 kW (204 PS)8.6 s210 km/h (130 mph)
GLE 350 d 4MATIC190 kW (258 PS)7.1 s225 km/h (140 mph)

Source: Mercedes-Benz W 166, de.wikipedia.org.

Dimensions

Length4,804 to 4,852 mm
Width1,926 to 1,971 mm
Height1,760 to 1,796 mm
Wheelbase2,915 mm
Kerb weight2,425 to 2,595 kg

Source: Mercedes-Benz W 166, de.wikipedia.org; EU type-approval data (EEA).

Body styles & production

Body stylesKombi
Produced2013–2016

Factory colours

Polar WhiteDiamond White TricoatBlackCavansite Blue MetallicIridium Silver MetallicPalladium Silver MetallicSteel Gray MetallicSelenite Gray MetallicCalcite WhiteObsidian Black MetallicAlabaster WhiteHyacinth Red/Designo Cardinal MetallicDiamond Silver MetallicPewter Silver MetallicCapri Blue MetallicVerde Brook MetallicBarolo RedCinnabar Red PearlAtlantic Blue

Trim levels

GLS 450 4MATICGLS 580 4MATICAMG GLS 63
