Mercedes GLK-Class 204X side profile — Mercedes GLK-Class wheel fitment

Mercedes GLK-Class wheel fitment — 204X

By Torque, AIWheelTech vehicle & fitment specialist · 2008–2015
The Mercedes GLK-Class 204X (2008–2015) uses a 5x112 bolt pattern, 66.6 mm centre bore, M14x1.5 bolts torqued to ~110 Nm. It accepts ~8J–9J wheels at ET38–ET56 front; staggered setups run 9.5J–11J rear (ET38–ET55). That is the short version of Mercedes GLK-Class wheel fitment; the full picture is below.

Overview

The Mercedes-Benz GLK-Class (model code X204) is a compact luxury crossover SUV produced from 2008 to 2015, debuting at the 2008 Beijing Auto Show. The name GLK is an acronym for Geländewagen Luxus Kompaktklasse, taking its name from the larger Mercedes-Benz GL-Class, which in turn was named after the G-Wagen or Geländewagen. Thus, the GL is the luxury-oriented version of the G, and GLK is the compact version of the GL.

Mercedes GLK-Class wheel fitment

Start with the hub. The Mercedes GLK-Class 204X spec table gives the bolt pattern and bore; the second table is the aftermarket window for Mercedes GLK-Class wheel fitment.

Bolt pattern (PCD)5x112
Centre bore66.6 mm
Bolt / threadM14x1.5 (bolts)
Wheel-bolt torque110 Nm
Seat typeradius
Factory setupstaggered
TPMSdirect
Run-flatYes

Aftermarket wheel sizes — read per position:

PositionWidthOffset
Front8J–9JET38–ET56
Rear (staggered)9.5J–11JET38–ET55

As a rule, each extra 1J of width wants roughly +8 to 10 ET to keep the wheel tucked. The exact offset and any spacer are confirmed by the fit-check.

Browse wheels that fit a Mercedes GLK-Class →Get them fitted (UK)

Dimensions

Kerb weight1,790 to 1,955 kg

Source: EU type-approval data (EEA).

Body styles & production

Produced2008–2015

Trim levels

GLK 220 CDI BlueEfficiencyGLK 320 CDI 4MaticGLK Edition 1

Factory colours

Obsidian Black MetallicDeep Black, Tiefschwarz, BlackBonamitsilber MetallicJade Green MetallicCapri Blue MetallicCuprit Brown MetallicBarolo Red MetallicMars RedArctic WhiteCubanitsilber MetallicBrillantsilber MetallicTenoritgrau Metallic, Steel Gray MetallicPalladium Silver MetallicSand Beige MetallicPolar WhiteDiamond White TricoatBlackCavansite Blue MetallicIridium Silver MetallicSteel Gray Metallic

History & notable variants

In 2015, the GLK-Class was replaced by the GLC as per the revised nomenclature adopted by the brand. Under this scheme, SUVs use the base name 'GL', followed by the model's placement in Mercedes-Benz hierarchy. The 'G' is for Geländewagen (German for off-road vehicle) and alludes to the long-running G-Wagen. This is followed by the letter 'L' that acts as a linkage with the letter 'C'—the GLC being the SUV equivalent to the C-Class.

Reliability & owner notes
