Mercedes GLS AMG wheel fitment — 63 4matic H1GLE
Quick answer on Mercedes GLS AMG wheel fitment: The Mercedes Amg Gls 63 4matic H1GLE (2020–2023) uses a 5x112 bolt pattern, 66.6 mm centre bore, M15x1.25 bolts. It accepts ~9J–10.5J wheels at ET30–ET45 front; staggered setups run 9J–12.5J rear (ET20–ET48).
Mercedes GLS AMG wheel fitment
Mercedes GLS AMG wheel fitment for the Mercedes Amg Gls 63 4matic H1GLE (2020–2023): the factory PCD, centre bore and bolt spec, then the aftermarket width and offset window we fit to.
| Bolt pattern (PCD) | 5x112 |
| Centre bore | 66.6 mm |
| Bolt / thread | M15x1.25 (bolts) |
| Seat type | radius |
| Factory setup | staggered |
| TPMS | direct |
| Run-flat | Yes |
Aftermarket wheel sizes — read per position:
| Position | Width | Offset |
|---|---|---|
| Front | 9J–10.5J | ET30–ET45 |
| Rear (staggered) | 9J–12.5J | ET20–ET48 |
Go wider and the offset has to rise with it, about 8 to 10 ET per extra 1J, or the wheel pokes past the arch. The fit-check settles the exact offset and any spacer.
Dimensions
| Kerb weight | 2,445 to 2,886 kg |
Source: EU type-approval data (EEA).
Body styles & production
| Produced | 2020–2023 |
Factory colours
Obsidian Black MetallicPolar WhiteSelenitgrau Metallic MatteSelenite Gray MetallicDesigno Hyazinthrot Pearl MetallicHyacinthrot MetallicDesigno Hyacinthrot MetallicBlackDeep BlackTiefschwarzSteel Gray MetallicTenoritgrau MetallicIridiumsilber Pearl MetallicIridium Silver MetallicIridium Silver Pearl MetallicCitrine Brown MetallicDiamond White PearlDiamantweiss MetallicDiamantweiss PearlMojavesilber Metallic
